General Tools RLD382P High Performance Refrigerant Leak Detector with Pump

Name: General Tools RLD382P High Performance Refrigerant Leak Detector with Pump
Brand: General Tools
SKU: GeneralRLD382P
Price: 205.54 USD
Availability: InStock

0 reviews | UPC: 681035003824 | Model: General Tools RLD382P

Compare

General RLD382P High Performance Refridgerant Leak Detector W/ Pump

RLD382P High Performance Refrigerant Leak Detector with Pump
Detects R-134a, R-404A, R-407C, R-410A,R-22 (Freon)
Uses pump to draw in gas, increasing sensitivity
Also uses semi conductor sensor and digital signal processing
Three-color display of Hi, Medium, Lo leak levels
Hi/Lo sensitivity switch
Includes flexible stainless steel gooseneck probe, reference source
Fast warmup
Redundant audible and visual alarms
Ambient refrigerant concentration reset
Auto power off
Low battery alert
RoHS, CE, WEEE approved

View Product Details

List Price: $289.00

In Stock:

View Payment Options

Recommended for you

Specifications
Sensitivities	3g/yr (Hi), 15g/yr (Med)and 30g/yr (Lo) for R-134a, R-22;4g/yr (Hi), 20g/yr (Med) and 40g/yr (Lo)for R-404A, R-407C, R-410A
Warmup Time	45 seconds
Auto Power Off	10 minutes of inactivity
Probe Length	15.5 in. (394mm)
Battery Life	7 hours of normal use
Operating Altitude	<6500 ft. (1980m)
Operating Temperature and Humidity	32° to 104°F (0° to 40°C), < 80%RH
Storage Temperature and Humidity	14° to 140°F (-10° to 60°C), < 70%RH
Dimensions	6.8 x 2.6 x 2.2 in.(173 x 66 x 56mm)
Weight	14.1 oz. (400g)
Power Source	4 'AA' batteries (included)

Tech Specs

HVAC Equipment and Instruments/Refrigerant HVAC/Refrigerant Leak Detectors Template
Style (Refrigerant Leak Detectors)	Pump
Adjustable Sensitivity Levels	Yes
Type of Alarm	Audible, Visual
Refrigerant & Gas Detected	410A Puron, Combustable Gases
Measurement Methods	Pump Driven
Response Time	45 SECONDS (45 s)
Audible Alarm	Yes
Visual Alarm	Yes
Flexible Probe	Yes
Headphones	No
Auto Zero	No
Battery Life	7 HR
Relay Output	No
Process Output	No
Test Equipment General Attributes
Unique Features	Semiconductor gas sensor Detection of R-134a, R-404A, R-410A, R-407C, R22 Freon gas Sensitivity (H/M/L): R-22, 134a 3g/year 15g/year 30g/year, R-404A, 407C, 410A 4g/year 20g/year 40g/year 15.5" (40cm) flexible stainless probe Reference Leak source included Ambient concentration reset Long-life, DC brushless fan Automatic zero and background compensation
Warranty	1 YEARS
Safety Approval	CE, RoHS Safety Approval WEEE
Product Weight	14.1 OUNCES (0.881 LBS) Product Weight 400gr.
Product Height	6.8 IN
Product Length	2.2 IN Product Length (173 x 66 x 56 mm)
Product Width	2.6 IN
Data Logging	No
HTS/Schedule B Number	8531.10.0045
ECCN Number	3A992
Battery Type	AA
Power Supply Voltage	Battery Powered
Country of Origin	United States
Shipping Height	3.00 IN
Shipping Length	13.00 IN
Shipping Width	10.00 IN
