| Detector |
| Detector Type |
120 x 160 uncooled focal plane array |
| NETD (Thermal Sensitivity) |
200 mK |
| Thermal |
| Temperature Range |
-10 to 250 °C (14 to 482 °F) |
| Accuracy |
±2 % or ±2 ºC (±3 % or 3 °C from -10 to 0 °C) |
| Optical |
| Optical Resolution |
90:1 |
| Slit Response Optical Resolution |
225:1 |
| Minimum Diameter Measurement Spot |
7 mm (0.27 in) at 61 cm (24 in) |
| Field of View (FOV) |
17 º Horizontal x 12.8 º Vertical |
| Target Sighting |
Single laser (Meets IEC Class 2 & FDA Class II requirements) |
| Controls and Adjustments |
| Focus |
Focusable, 61cm (24 in) to infinity |
| Temperature Scale |
ºC or ºF selectable |
| Palettes |
Gray, Ironbow or Rainbow |
| Measurement Modes |
Automatic, Semi-Automatic or Manual |
| LCD Backlight |
Bright, Dim, Off-Selectable |
| Adjustable Emissivity |
0.10 to 1.00 by 0.01 |
| Reflected Background Temperature |
-50 to 460 ºC (-58 to 860 ºF) |
| Environmental |
| Ambient Operating Temperature |
-10 to 50 ºC (14 to 122 ºF) |
| Relative Humidity |
10 to 90 % Non-Condensing |
| Storage Temperature |
-25 to 70 ºC (-13 to158 ºF) [without batteries] |
| Other |
| Storage Capacity |
100 images |
| Power |
Rechargeable battery pack or 6 AAs (not included) |
| Battery Life |
Minimum 5 hours continuous use |
| Image Frame Rate |
20 Hz |
| Thermal Analysis Software |
InsideIR (included) |
| PC Software Operating Systems |
Microsoft® Windows® 2000® or XP® |
| Weight (includes batteries) |
1 kg (2.2 lb) |
| Warranty |
1 year (U.S. only) |
