The CopperPro Series II is the complete test set for qualifying your local loop for DSL Services including ADSL, ADSL2/2+, VDSL and Special Services
CopperPro Series II is the latest generation of the leading copper loop test and analysis test sets. It provides a complete range of troubleshooting, fault locating, testing and qualification capabilities, all in a rugged, handheld easy-to-use DSL test set. New features include broadband noise identification for VDSL, advanced TDR capabilities for locating short bridge taps and other VDSL affecting impairments, and an optional VDSL modem for verifying service connectivity and performance.
Streamline Trouble Calls
Step-by-step instructions make CopperPro Series II a breeze to set up. Use the unique TDR Auto-Test to:
- Zero in on faults such as short bridge taps and shorted or open pairs.
- Count and locate load coils
- Locate high resistance faults precisely, no matter the cable makeup.
- Easily identify the source of broadband interference and impulse noise, up to VDSL bandwidth.
Advanced features to support next generation services
The CopperPro Series II offers several new features focused specifically on helping you install and maintain next generation services. These include:
- Bandwidth to 18 MHz to support ADSL2+ and VDSL technologies
- Identification of broadband noise for VDSL, including crosstalk and impulse noise
- Advanced TDR capabilities for locating short bridge taps and other hard-to-detect impairments to DSL performance
- Golden modem options for ADSL, ADSL2+, and VDSL
Seamlessly integrate field testing with backoffice systems
Not only does the CopperPro Series II collect and store comprehensive test data, it also integrates with NetDSL plant conditioning and EXP Technician Productivity solutions to automate job close out and data base updates. By integrating with the NetDSL process, the CopperPro Series II eliminates duplicate tasks and paperwork and requires no additional servers, systems, or interfaces.
As part of the Fluke Networks EXP productivity solution, the CopperPro Series II dramatically improves technician efficiency while significantly reducing repeats. Automated close-out tests assure consistent, complete testing and centralized test results make it easy to track results and monitor technical productivity.
Comprehensive set of copper loop testing functions
A comprehensive set of copper loop testing functions The CopperPro Series II packs all the test, analysis, and troubleshooting capabilities an OSP technician needs into one integrated handheld tool that gives a clear vision of your local loop, including:
- DCV and ACV measurement (snapshot and continuous)
- Shorts, grounds, and loop resistance with distance conversion
- Resistive fault location (Wheatstone and K-Test)
- Load coil counter with estimated distance to fault and impedance versus frequency graph to distinguish real results from false positives
- Multimode TDR with Auto-Test: pair 1 test, compare pair 1 and 2, difference between pair 1 and 2, pair 1 monitor, pair 2 to pair 1 crosstalk, compare pair 1 to stored trace
- Broadband noise and level spectral analysis with interference masks (VDSL bandwidth)
- Broadband loss impulse noise reduction (VDSL bandwidth)
- ADSL, ADSL2+, VDSL2 and XDSL Auto-Test for pair qualification (varies by model)
- Optional ADSL1/2/2+ Modem (ATU-R)
- Optional VDSL Modem (ATU-R and ATU-C)
- Broadband terminated test macros (Terminator, SmartStrap, MyHelper, FED)
- Leakage stress test to 200V
- Loop device counter
- Tracing tone with four modes
- Voice frequency noise ? metallic and power influence
- Voice frequency loss
- Voice frequency longitudinal balance
- Voice frequency tone generator
- Automated POTS Auto-Test
- Dial set and non-intrusive line monitor
- Voice frequency terminated and dial-up test macros (SmartStrap, MyHelper, FED, SASS, DATU, SmartPro)
Expedite Installation and Maintenance
CopperPro Series II makes fast work of installing and maintaining service. The one-button POTS Auto-Test quickly documents status before and after work is complete. The CopperPro also gives you a clear view of all the basic tests you need to ensure top performance, including:
- AC and DC voltage
- Loop current
- Circuit noise
- Balance and leakage
- Caller ID/ANI
Plus, you can quickly run loss and slope test with its automated dial-up testing, and use the built-in dial set with phone number storage. You can also verify xDSL connectivity, performance and capacity up to VDSL rates with optional xDSL golden modems.
