• Commissioning and maintaining variable speed drives
• Installing and testing of dc power systems
• Measurement of harmonics voltage and current on industrial systems
• Quick data evaluation with large bright display for waveform, chart and multi-parameter display
• Immediate harmonics analysis with ‘live’ bargraph display (to 25th)
• Check for problems at the service entrance with CAT IV 600 V safety rating
• Trend measurements by internal data logging of up to 5 parameters for 24 hours
• True RMS voltage, current, and power on ac and dc current measurement up to 2000 A
• Comprehensive range of measurement parameters including V, A, Hz, Crest Factor,THD, DF, W, VA, VAR, kWh and Power Factor even for distorted waveforms
• Monitor the effects of loads with dc Ripple measurement
• Quick reporting with 8 data set memory and time stamped min, max, average recording
• Flexible applications with three-phase power capability for balanced loads.
• Analyze data and generate reports with Optional WinLog software

Advantages:

• Current clamp, power quality meter, oscilloscope and data logger in one instrument
• Large backlit display for waveform, chart and multi parameter display
• AC/DC True RMS measurements
• Enhanced EMC performance for power electronics applications
