AC Current
![]()
| | Range | | 333: | 0-400.0 A | | 334,335,336: | 0-600.00 A | | 337: | 0-999.9 A | | | Accuracy | | 333, 334, 335: | 2% ± 5 counts (50/60 Hz) | | 336, 337: | 2% ± 5 counts (10-100 Hz) | | | 6% ± 5 counts(100-400 Hz) | | | Crest Factor | | 333, 334: | Not Applicable | | 335: | 2.4@500 A, 2.0@600 A add 2% for CF>2 | | 336: | 3@500 A, 2.5@600 A add 2% for CF>2 | | 337: | 3@500 A 2.5@600 A 1.42@1000 A add 2% for CF>2 | | | AC Response | | 333, 334: | Averaging | | 335, 336, 337: | True-rms | | |
| In-Rush | | Integration Time | | 333: | Not Applicable | | 334, 335, 336, 337: | 100 ms | | |
DC Current
![]()
| | Range | | 333, 334, 335: | Not Applicable | | 336: | 0-600.0 A | | 337: | 0-999.9 A | | | Accuracy | | 333, 334, 335: | Not Applicable | | 336, 337: | 2% ± 3 counts | | |
| AC Volts ![]()
| | Range | | 333, 334, 335, 336, 337: | 0-600.0 V | | | Accuracy | | 333, 334, 335: | 1% ± 5 counts (50/60 Hz) | | 336, 337: | 1% ± 5 counts (20-100 Hz), 6% ± 5 counts (100-400 Hz) | | | AC Response | | 333, 334: | Averaging | | 335, 336, 337: | True-rms | | |
| DC Volts ![]()
| | Range | | 333, 334, 335, 336, 337: | 0-600.0 V | | | Accuracy | | 333, 334, 335, 336, 337: | 1% ± 5 counts | | |
| Resistance ![]()
| | Range | | 333: | 0-600.0 Ω | | 334, 335, 336, 337: | 0-600.0 Ω, 601-6000 Ω | | | Accuracy | | 333, 334, 335, 336, 337: | 1.5% ± 5 counts | | |
| Continuity | | | | 333, 334, 335, 336, 337: | ≤30 Ω | | |
| Frequency ![]()
(AC Only) | | Range | | 333, 334, 335, 336: | Not Applicable | | 337: | 0-600.0 Ω, 601-6000 Ω | | | Accuracy | | 333, 334, 335, 336: | Not Applicable | | 337: | 5-400 Hz | | | Trigger Level | | 333, 334, 335, 336: | 0.5% ± 5 counts | | 337: | 10-100 Hz > 5 A 5-10 Hz, 100-400 Hz > 10 A | | |
