| Model |
Ti480 |
Ti450 |
Ti400 |
Ti300 |
| Resolution |
640 x 480 (307,200
pixels) or 1280 x 960
with SuperResolution |
320 x 240 (76,800 pixels) or 640
x 480 with SuperResolution |
320 x 240 (76,800 pixels) |
240 x 180 (43,200 pixels) |
| SuperResolution |
Yes, on camera and in
software. Captures and
combines 4x the data to
create a 1280 x 960 image |
Yes, on camera and in
software. Captures and
combines 4x the data to create
a 640 x 480 image |
- |
| Temperature measurement range (not calibrated below -10 °C) |
" -20 °C to +800 °C
(-4 °F to +1472 °F)"
|
" -20 °C to +1200 °C
(-4 °F to +2192 °F)" |
" -20 °C to +650 °C
(-4 °F to +1202 °F)" |
| Temperature measurement accuracy |
± 2 °C or 2 % (at 25 °C nominal, whichever is greater) |
| On-screen emissivity correction |
Yes (both value and table) |
| Thermal sensitivity (NETD) Best possible |
= 0.05 °C at 30 °C target temp
(50 mK) |
= 0.03 °C at 30 °C target temp
(30 mK) |
= 0.05 °C at 30 °C target temp (50 mK) |
| IFOV with Standard infrared lens type |
0.93 mRad, D:S 1065:1 |
1.31 mRad, D:S 753:1 |
1.75 mRad, D:S 565:1 |
| Field of view |
34 °H x 24 °V |
24 °H x 17 °V |
| Minimum focus distance |
15 cm (approx. 6 in) |
| IR-Fusion® technology |
Picture-in-picture (PIP), full screen infrared, AutoBlend™ mode and on-camera continuous blending |
| IFOV with optional 2x telephoto smart lens |
0.46 mRad, D:S 2145:1 |
0.64 mRad, D:S 1529:1 |
0.87 mRad, D:S 1147:1 |
| Field of view |
17 °H x 12 °V |
12 °H x 9 °V |
| Minimum focus distance |
45 cm (approx. 18 in) |
| IR-Fusion® technology |
Picture-in-picture and full screen |
| IFOV with optional 4x telephoto smart lens |
0.23 mRad, D:S 4300:1 |
0.33 mRad, D:S 2941:1 |
0.44 mRad, D:S 2208:1 |
| Field of view |
8.5 °H x 6 °V |
6.0 °H x 4.5 °V |
| Minimum focus distance |
1.5 m (approx 5 ft) |
| IR-Fusion® technology |
Picture-in-picture and full screen |
| IFOV with optional wide-angle smart lens |
1.85 mRad, D:S 525:1 |
2.62 mRad, D:S 377:1 |
3.49 mRad, D:S 283:1 |
| Field of view |
68 °H x 48 °V |
46 °H x 34 °V |
| Minimum focus distance |
15 cm (approx. 6 in) |
| IR-Fusion® technology |
Full screen |
| MultiSharp Focus |
Yes, focused near and far, throught the field of view |
- |
| LaserSharp® Auto Focus |
Yes , for consistently in-focus images. Every. Single. Time. |
| Color alarms (temperature alarms) |
High-temperature , low-temperature, and isotherm (within range) |
| Text annotation |
Yes |
| Voice annotation |
60 seconds maximum recording time per image; reviewable playback on camera, optional bluetooth headset
available but not required |
| IR-PhotoNotes™ |
Yes (5 images) |
| Fluke Connect® app compatible |
Yes*, connect your camera to your smartphone and images taken automatically upload to the Fluke Connect app
for saving and sharing |
| Software |
Fluke Connect desktop software* - full analysis and reporting software with access to the Fluke Connect system |
| WIFI connectivity |
to PC, iPhone® and iPad® and WiFi to LAN* |
| Record video |
Standard and Radiometric |
| Streaming Video |
Via USB to PC and HDMI to HDMI compatible screens |
| Auto capture (temperature and interval) |
Yes |
