Automated Procedures
Setting up automated calibration procedures with the Fluke 754 is simple. They can be used in a variety of applications including linear transmitters, DP flow transmitters, and one & two point limit switches. After set up, the 754 will perform the necessary tests and calculate any errors. Users can then easily view final results and quickly locate out of tolerance points.
Custom Units
Gives users the ability to map one unit of measurement to another such as mV to ºC or ºF. This allows the 754 to be used with accessories that output in mV and still properly document th test using an unsupported unit of measurement including parts per million or rpm.
User-entered Values
Give users the ability to record results from external measurements devices such as a panel meter. This allows for comprehenssive data recording.
Limit Switch Calibration
Limit switch calibration is simple and fast with the 754's automated procedures. Procedures can be used for either one or two point switches and measure voltage, current, pressure and temperature.
Differential Pressure Flow Instrument Calibration
Built in square root functions quickly calibrate DP flow instruments.
Multifunctional
The 754 is able to calibrate temperature, pressure, voltage, current, resistance, and frequency. With these capabilities and the ability to both measure and source, the 754 can troubleshoot and calibrate.
Powerful & Simple
Users will find the Fluke 754's user interface easy to navigate and follow step by step through each procedure. Have your unit up and running with in a few minutes. Saving valuable time and money.
Records and documents results
The Fluke 754 seemlessly records all calibration data, perminately eliminating the need to transcribe results on a computer or piece of paper. This ensures that all results are recorded properly. The USB connection allows for easy data transfer to your computer.
Truly hand-held
Despite all of its features, the 754 is still able to maintain a compact and easy to transport design. It is compact enough to fit into most tool bags and can be used in tight work areas. The rechargeable lithium ion battery provides enough battery for a standard day's use (approximately 10 hours)
Bright white display
The bright white display featured on the 754 offers users the ability to view results in real time indoors or outdoors. With 3 brightness settings, this display will work in any environment.
Soft keys
Fluke has added soft keys to the 754 giving users instant access to task lists, automated procedures, scaling, min/max, stepping and ramping, and review memory.
Rugged and reliable
Fluke has designed the 754 to withstand the rigors of daily usage. The strong urethane case can withstand the rough conditions brought on by an industrial environment.
Built-in algebraic calculator
Built-in math functions eliminate the need to make separate calculations after data is recorded. Eliminating opportunity for error during data transcription.
Operating Modes
Designed to be an all-in-one tool, the 754 has three separate operating modes including measure, source and a combination of both measure and source. This eliminates the need for multiple tools.
