Voltage inputs |
Number of inputs |
4 inputs, 3 phases and neutral referenced to PE (5 connectors) |
Measurement category |
1000 V CAT III / 600 V CAT IV |
Maximum input voltage |
1000 V rms / 1000 V dc (1700 Vpk) Nominal voltage range Wye and single phase: variable (50 V - 1000 V)
Delta: Variable (100 V - 1000 V)
IEC 61000-4-30 Class A compliance for the nominal voltages (Vdin) 100 V - 690 V |
Input impedance |
10 MΩ between P-P and P-N, 5 MΩ between P-PE and N-PE |
Bandwidth |
DC to 30 kHz for PQ measurements, excluding transients |
Resolution |
24-bit synchronous sampling |
Sampling frequency |
80 kS/s at 50/60 Hz |
Scaling |
1:1, variable for use of potential transformers |
Voltage transients |
Measurement range |
±8 kV |
Sampling rate |
1775: 1 MS/s |
1777: 1 MS/s, 20 MS/s |
Bandwidth |
DC to 1 MHz |
Trigger |
Adjustable trigger level. Triggers on high-frequency components > 1.5 kHz |
Resolution |
14-bit synchronous sampling |
Current inputs |
Number of inputs |
4 inputs 3 phases and Neutral, range selected automatically to attached sensor |
Range |
AC |
1 A to 1500 A with i17XX-FLEX1500 12
1 A to 1500 A with i17XX-FLEX1500 24
3 A to 3000 A with i17XX-FLEX3000 24
6 A to 6000 A with i17XX-FLEX6000 36
40 mA to 40 A with clamp i40s-EL
4 A to 400 A with clamp i400s-EL |
DC |
20 A to 2000 A with 80i-2010-EL clamp |
Bandwidth |
DC to 30 kHz |
Resolution |
24-bit synchronous sampling |
Sampling frequency |
80 kS/s at 50/60 Hz |
Scaling |
1:1, variable |
Input voltage |
Clamp: 50 mV / 500 mV rms; CF 2.8
Rogowski Coil: 15 mV / 150 mV rms at 50 Hz, 18 mV / 180 mV rms at 60 Hz
CF 4 all at nominal probe range |
Input impedance |
11 kΩ |
Standard compliance |
Power |
IEEE 1459 |
Harmonics |
IEC 61000-4-7: Class 1
IEEE 519 (short time and very short time harmonics) |
Flicker |
IEC 61000-4-15 Class F1 |
Power quality |
IEC 61000-4-30 Class A, IEC 62586 PQI-A-PI |
Power quality compliance |
EN 50160 + GOST + NEQUAL + NETCODE + FOL |
Interfaces |
Ethernet |
1 Gbit/s 1000BASE-T |
USB type A |
USB 2.0 high speed for USB flash drives to transfer measurement data, firmware updates and license installation. Max. supply current: 500 mA |
USB-C |
USB 2.0 high speed for data download to PC and calibration (requires USB type A to USB-C or USB-C to USB-C cable)
Auxiliary power supply for the Analyzer (requires USB C power adapter PD 2.0 or higher with 9 V 1.8 A support)
USB 3.0 super-speed for USB-C flash drives to transfer measurement data, firmware updates and license installation. Max. supply current: 900 mA |
WiFi/BLE module1 |
802.11 ac 2.4 GHz / 5 GHz, support for concurrent access point and client mode
Bluetooth 5.0/BLE
Antenna: Internal and external2 |
LTE/4G module3 |
LTE-A Cat 12
Worldwide LTE-A and UMTS/HSPA+ coverage
Antenna: External2 |
GPS |
MCX connector to attach a GNSS antenna for GPS/GLONASS2 |
- Not in 177X/BASIC versions
- Requires 5m extension cable, Fluke p/n 5263915
- Availability and supported providers vary by country. Check with your local Fluke representative
|
