General |
Dimensions (with module and battery installed) |
10.3 in x 5.3 in x 2.9 in (26.2 cm x 13.5 cm x 7.3 cm) |
Weight (with module and battery installed) |
3.5 lb (1.6 kg) |
Display |
5.7 in (14.5 cm) LCD with projected capacitance touch screen, 480 x 640 pixels |
AC adapter |
Input: 100-240 Vac, 50-60 Hz, 1.0 A
Output: +15 Vdc, 2.0 A |
Battery type |
Lithium ion battery pack, 7.2 V |
Battery life |
Approximately 3-4 hours depending on type of usage, 4 from 10% capacity to 90% capacity with the unit powered off |
Memory |
Internal: 2 GB shared between system and user files
SD card: 4 GB, brand and model selected for optimal performance
USB 2.0 type A port: for use with USB mass storage devices |
Network analysis ports |
Two RJ-45 10/100/1000BASE-T Ethernet
Two SFP 100BASE-FX/1000BASE-X Ethernet |
Management port |
One RJ-45 10/100BASE-T Ethernet |
Wi-Fi adapter data rate |
802.11a: 6/9/12/24/36/48/54 Mbps
802.11b: 1/2/5.5/11 Mbps
802.11g: 6/9/12/24/36/48/54 Mbps
802.11n (20 MHz): MCS0-23, up to 216 Mbps
802.11n (40 MHz): MCS0-23, up to 450 Mbps |
Wi-Fi adapter operating frequency |
2.412 ~ 2.484 GHz (Industrial Scientific Medical Band)
5.170 ~ 5.825 GHz |
Wi-Fi security |
64/128-Bit WEP Key, WPA, WPA2, 802.1X |
Environmental and Regulatory |
Operating temperature |
32°F to 122°F (0°C to 50°C) |
Battery charging temperature |
32°F to 104°F (0°C to 40°C) |
Storage temperature |
-40°F to 160°F (-40°C to 71°C)
-4°F to 122°F (-20°C to 50°C) for periods longer than 1 week |
Operating relative humidity (% RH without condensation) |
5% to 45% at 32°F to 122°F (0°C to 50°C)
5% to 75% at 32°F to 104°F (0°C to 40°C)
5% to 95% at 32°F to 86°F (0°C to 30°C) |
Shock and vibration |
Meets the requirements of MIL-PRF-28800F for Class 3 Equipment |
Safety |
CAN/CSA-C22.2 No. 61010-1-04, IEC 61010-1:2001 |
Operating altitude |
13,123 ft (4,000 m), 10,500 ft (3,200 m) with AC adapter |
Storage altitude |
39,370 ft (12,000 m) |
Pollution degree |
2 |
EMC |
EN 61326-1:2006 |
Certifications and Compliance |
Conformite Europeene. Conforms to the requirements of the European Union and the European Free Trade Association (EFTA). |
Listed by the Canadian Standards Association. |
onforms to relevant Australian standards. |
