T300 with NIST Calibration
The FLIR T300 are professional level infrared cameras at truly affordable prices. They are jam-packed with many of the features found in higher-model FLIR infrared cameras.
Picture-in-Picture and much more
With the exclusive FLIR Picture-in-Picture capability, you combine infrared and visible light detail to easily show hidden trouble. Speed through reporting of trouble spots with the help of FLIR's QuickReport software. QuickReport includes easy image organization tools and report templates so you can concentrate more on your IR inspection.
Industrial applications for the FLIR T-Series
Examples of industrial applications where the FLIR T-Series cameras are an invaluable tool for professional thermographers in spotting anomalies before a break down is a fact, are: production process supervision, measurement of heat development electrical and mechanical devices, detect blocked pipe work and insulation defects, enhance work safety and much more.
FLIR T300 Features
- High Resolution IR Images — 76,800 pixels (320 x 240) Infrared resolution
- Visible Light Digital Camera — 3.1MP resolution with flash provides sharp images regardless of lighting conditions
- 2X Continuous Zoom — Zoom with auto/manual focus
- Rotating Lens — Rotating lens detents up to 120° for easy viewing angle
- Scalable Picture in Picture (PIP) Fusion — Displays thermal image super-imposed over a digital image
- Video Lamp — Allows the visual camera and fusion to be used in poorly lit environments
- High Temperature Range — From –4 to 1202°F (–20 to 650°C) targeting electrical and industrial applications; Optional 2192°F/1200°C temperature available
- ± 2% Accuracy — reliable temperature measurement
- Thumbnail Image Gallery — Allows quick search of stored images
- Li-Ion Rechargable Battery — lasts >4hrs continuous use; replaceable
- Copy to USB — Easy upload of a single image or a folder from the camera to a USB memory stick
- Laser LocatIR™ Pointer — Pinpoints a reference spot with a laser and aligns a marker to it on the image
- IR Window Correction — Menu settings allow you to account for transmission loss through IR windows
- Voice Comment Recording — on images & can be integrated onto report
- Wireless Communication — Bluetooth ® Transmitter with METERLiNK™
- Includes — SD Memory Card (stores >1000 Radiometric JPEG images), Li-Ion rechargeable battery with 100-260V AC adaptor/charger, two rechargeable batteries, 2-bay battery charger, QuickReport software, USB Mini-B cable, Bluetooth ® USB micro adapter, sun shield, stylus pen, headset, camera lens cap, and hard transport case
- Interchangeable Optics — Optional 6°, 15°, 45°, 90°, Close up: 100, 50, 25μm, easily attach to the camera
Superior IR Images -
Razor-sharp thermal images with up to 76,800 pixels (320 x 240) for greater accuracy from farther away
Visible Light Digital Camera with Video Lamp -
3.1 megapixel resolution with video lamp provides clear images in any lighting conditions
Rotating Optical Block -
Ergonomic lens system rotates up to 120° for easy, comfortable viewing when capturing images from challenging angles
Scalable P-i-P and Thermal Fusion -
Display both the thermal and visible images onscreen for easy identification and control the size of the Picture-in-Picture window
MeterLink
Wirelessly transmit vital diagnostic data such as amperage, voltage, and resistance from clamp meters directly to the camera for annotating thermal images.
Be sure you?re getting critical electrical load readings so you can make the right call. Quantify the severity of electrical problems with MeterLink-enabled clamp meters that use Bluetooth wireless communication to send data to the FLIR camera for annotation on stored thermal images. Contact FLIR to learn about other tools that connect with MeterLink.
InstantReport
Generate a professional PDF document in the camera without an external computer and complete the job before you leave the site.
Create professional reports on board your camera with InstantReport. FLIR's analysis software has always offered professional results and been easy to use. Now, create reports without a PC! InstantReport includes thermal and visual images along with your measurements and analysis tools, and text & sketch annotations, in a standard PDF document that's easy to share right from the touchscreen.
Unmatched Warranty -
FLIR's exclusive Double Diamond warranty covers the whole camera for 2 years, the battery for 5 years, and the detector for 10 full years. No one but FLIR can offer peace of mind like this because no one but FLIR builds their own detectors.
Applications
Utility Market — Utilities worldwide use infrared cameras to locate problems or to detect hot spots and other problems before they turn into costly failures and production downtime or dangerous electrical fires.
Electrical Inspections — With FLIR thermal imaging cameras electricalcontractors can scan electricalcabinets/panels and components for a non-contact view of conditions.
Software Packages
QuickReport ™ PC software enables users to Organize, Analyze and Create Reports with FLIR Cameras.
FLIR BuildIR Software package specifically designed to carry out advanced analysis of building structures. It is used to analyze images taken with an infrared camera, and create inspection reports based on these images.
FLIR Reporter Ver. 8.5 is a powerful software for creating compelling and professional,fully customized, easy-to-interpret reports in a standard MS Word Document. You can create a report by simply Dragging and Dropping your images on a desktop icon or using the Wizards to guide you step-by-step through the process. The saved document is a ‘live’ report with full access to the analysis tools and temperature measurement data. The reports can be multi-page and include all of your IR inspection data -infrared and visual images, temperature measurements, voice comments and text notes.
Panorama Function
This unique function allows you to conveniently piece together normal sized imagesto create one large image for a wide angle view of the area being measured by usingFLIR BuildIR or Reporter Software package
