| General Specifications |
| Name |
Zenmuse X5 |
| Dimensions |
120 (W) x 135 (H) x 140 (D) mm |
| Weight |
530 g (Including original lens, balancing ring, lens hood, Micro SD card) |
| Operating Temperature |
32° to 104° F (0° to 40° C) |
| Camera |
| lens |
Replaceable lens M43 mount supporting auto-focus |
| Supported Lenses |
DJI MFT 15mm f/1.7 ASPH
Panasonic Lumix G Leica DG Summilux 15mm f/1.7 ASPH
Olympus M.Zuiko Digital ED 12mm f/2.0
Olympus M.Zuiko Digital ED 17mm f/1.8
Olympus M.Zuiko Digital ED 25mm f/1.8
Olympus M.Zuiko Digital ED 45mm f/1.8 (For still photography)
Olympus M.Zuiko Digital ED 14-42mm f/3.5-5.6 EZ (For still photography) |
| Sensor |
Type 4/3 CMOS sensor |
| Effective Pixels |
16 M |
| Max Resolution |
4608x3456 |
| ISO Range |
100 to 25600 |
| Electronic Shutter Speed |
8 to 1/8000 s |
| Field of View |
DJI MFT 15mm f/1.7 ASPH 72° |
| Still Photography Modes |
Single shot
Burst shooting:3/5/7 frames
Auto Exposure Bracketing (AEB):3/5 bracketed frames at 0.7EV bias
Time-lapse |
| Video Resolution |
UHD:4K (4096×2160) 24/25p, 4K (3840×2160) 24/25/30p,2.7K (2704×1520) 24/25/30p;
FHD:1920×1080 24/25/30/48/50/60p |
| Max Video Bitrate |
60 Mbps |
| Supported File Systems |
FAT32 (≤ 32 GB), exFAT (> 32 GB) |
| Photo Formats |
JPEG, DNG |
| VideoFormats |
MP4/MOV (MPEG-4 AVC/H.264) |
| Supported Storage Devices |
Class 10 or UHS-1 or above Micro SD cards
Max capacity of 64 GB |
| Default Lens |
| Name |
DJI MFT 15mm f/1.7 ASPH |
| Focal length |
f=15 mm (35 mm format equivalent 30 mm) |
| Aperture Type |
7 diaphragm blades/circular aperture diaphragm |
| Maximum Aperture |
F1.7 |
| Minimum aperture value |
F16 |
| Lens construction |
9 elements in 7 groups (3 aspherical lenses) |
| In focus distance |
0.2 m to ∞ (from the focus distance reference line) |
| Mount |
Micro Four Thirds Mount |
| Angle of View |
72° |
| Max. diameter |
Approx. 2.26 inches (57.5 mm) |
| Overall length |
Approx. 1.42 inches (36 mm) |
| Mass |
115 g |
| Gimbal |
| Angular Vibration Range |
±0.02° |
| mount |
Detachable |
| Controllable Range |
Pitch:-90° to +30°
Pan:±320° |
| Max Controllable Speed |
Pitch:120°/s
Pan:180°/s |
| Status LED |
| The Status LED describes the working status of the camera. |
| Status LED |
| Solid Green |
| Blinks Green quickly (0.1 on, 0.2s off) |
| Blinks Green once (0.2s off) |
| Blinks Green 3 times (0.2s on, 0.2s off) |
| Blinks Red slowly (0.8s on, 0.8s off) |
| Blinks Green and Red alternatively (0.8s Green, 0.8s Red) |
| Blinks Red quickly (0.2s on, 0.3s off) |
| Solid Red |
| Blinks Red twice (0.1s on, 0.1s off) |
| Camera Status |
| Powered on; system is on standby. |
| System is warming up. |
| Taking a single photo. |
| Burst shooting 3 to 5 photos. |
| Recording video. |
| Firmware update in progress. |
| SD card error. |
| Firmware update failed. |
| Camera overheated. |
