| Sensor Specifications |
| Detector Type |
320 x 256 VOx Microbolometer |
| Video Refresh Rate |
60 Hz |
| Start Up |
< 6 seconds |
| Image Processing |
FLIR Proprietary Digital Detail Enhancement™ |
| System Specifications |
| Lens System |
50 mm; F/1.0 |
| Optical Magnification |
4× |
| Field of View (H x V) |
4.5° × 3.5° |
| Digital Zoom |
1x, 2x, 4x |
| Diopter Adjustment Range |
-5 to +5 dpt |
| Focusing Range |
10 m to infinity (not focusable) |
| Eye Relief |
45 mm |
| Display |
Quad-VGA (1280 x 960) FLCOS |
| Video Output |
Digital Video |
| Temperature Imaging Modes (Image Palettes) |
White Hot, Black Hot, Rainbow High Contrast, Ironbow, Sepia, Arctic, Outdoor Alert |
| Reticle Type |
Dot 4 MOA, Line Dot, Cross Center Dot, Cross, Crosshair, and “No Reticle” |
| Reticle Color |
Black, White, Red, Cyan |
| Boresight Adjustment Type |
Digitally Controlled |
| User Interface |
| Operation Switch |
On/ Off/ Standby Mode |
| Control Panel Buttons |
Configures Operational Settings:
• Display Brightness Control
• Image Palette Control
• Digital Zoom Control
• Reticle Color Control
• Reticle Pattern Control
• Boresighting Adjustment
• On-Screen Menu Navigation |
| Diopter Adjustment Ring |
Adjusts the Eyepiece Diopter |
| Interfacing |
| USB-C Connector |
Digital Video Out, Laser Range Finder Connections |
| Power |
Battery Type
Battery Life (Operating) |
Two CR123A 3V Lithium batteries
Up to 4 hr at 20c |
| Environmental |
| Operating Temperature Range |
-20°C to +50°C (-4°F to +122°F) |
| Storage Temperature Range |
-40°C to +60°C (-40°F to +140°F) |
| Physical |
| Weight |
0.81 kg (1.78 lbs) |
| Size |
259x68x84 mm (10.2x2.7x3.3 in) |
| Weapon Mount Type |
Picatinny, MIL-STD 1913, and Weaver Rails |
| Color (housing) |
Black |
| Country Of Origin |
USA |
| Height of the Scope above axis above Rail |
42mm (1.65in) |
