| Image and Optical Data |
| IR Resolution |
160 × 120 (19,200 pixels) |
| Thermal Sensitivity/NETD |
<70 mK |
| Field of View |
(FOV) 57° × 44° |
| Distance-to-Spot Ratio |
30:1 |
| Minimum focus distance |
0.3 m (0.98 ft.) |
| Imaging Range |
–25°C to 550°C (–13°F to 1022°F) |
| Image Frequency |
8.7 Hz |
| Focus |
Fixed |
| Digital Camera |
2 MP, 71° × 56° FOV |
| Image Presentation and Modes |
| Display Resolution |
320 × 240 pixels |
| Screen Size |
2.4" color LCD, portrait orientation |
| Aspect Ratio |
4:3 |
| Image Adjustment |
Automatic |
| Visual Image |
Yes |
| MSX® |
Yes |
| Gallery |
Yes |
| Color Palettes |
Iron, Rainbow, White hot, Black hot, Arctic, Lava |
| Image Storage Capacity |
4 GB for storage of up to 50,000 pictures |
| Image File format |
JPEG |
| Measurement and Analysis |
| Camera Temperature Range |
–25°C to 550°C (–13°F to 1022°F) |
| Measurement Accuracy |
±1.5°C (2.7°F) for temperatures 50°C to 100°C (122°F to 212°F)
Up to ±3°C (±5.4°F) for temperatures -25°C to 50°C (-13°F to 122°F)
Up to ±3°C (±5.4°F) for temperatures 100°C to 550°C (212°F to 1022°F) |
| IR Temperature Resolution |
0.1°C (0.2°F) |
| IR Thermometer Measurement |
Continuous scanning |
| Spot Meter |
Center spot on/off |
| Emissivity correction |
Yes: 4 preset levels with custom adjustment of 0.1 to 0.99 |
| Set-up Commands |
Local adaptation of units, language, date, 0.99
Screen Brightness (high, medium, low)
Gallery, deletion of images |
| General |
| Laser pointer |
Center spot and circular area |
| Laser |
Class 1 |
| Interfaces |
USB 2.0, Bluetooth® BLE |
| USB |
USB Type-C: data transfer/power |
| Available Languages |
Czech, Danish, Dutch, English, Finnish, French, German,
Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish,
Portuguese, Russian, simplified Chinese, Spanish, Swedish, traditional Chinese, Turkish |
| Flashlight |
Bright LED flashlight |
| Battery Operating Time |
5 hours continuous scanning |
| Battery Type |
Rechargeable Li-ion battery |
| Battery Voltage |
3.7 V |
| Battery Charging Time |
4 hours to 90%, 6 hours to 100% |
| Power Management |
Adjustable: off, 5 min, 15 min, 30 min |
| IP Rating |
IP54 (IEC60529) |
| Drop |
Designed for 2 m (6.56 ft.) |
| Safety |
CE/CB/EN61010/UL |
| Operating Temperature Range |
–10°C to 45°C (14°F to 113°F) |
| Tripod mounting |
UNC 1/4”-20 |
| Weight (including battery) |
0.394 kg (13.9 oz.) |
| Size (L x W x H) |
210 mm × 64 mm × 81 mm (8.3" × 2.5" × 3.2") |
| Box Contents |
Thermal camera, wrist strap lanyard, USB cable, pouch, printed documentation |
