| OVERVIEW |
| Accuracy |
±2°C (±3.6°F) or ±2% of reading |
| IR Resolution |
640 × 480 pixels |
| Laser Pointer |
Yes |
| Object Temperature Range |
-20°C to 120°C (-4°F to 248°F); 0°C to 650°C (32°F to 1202°F); 300°C to 2000°C (572°F to 3632°F) |
| Programmable Buttons |
2 |
| Thermal Sensitivity/NETD |
<30 mK at 30°C (42° lens) |
| Text |
Predefined list or touchscreen keyboard |
| Time Lapse |
10 sec to 24 hrs |
| Voice |
60 sec. recording added to still images or video via built-in mic (has speaker) or via Bluetooth |
| Weight & Dimensions (without lens) |
1.3 kg (2.9 lbs), 140 × 201 × 84 mm (5.5 × 7.9 × 3.3 in) |
| CONNECTIONS & COMMUNICATIONS |
| Communication Interfaces |
USB 2.0, Bluetooth, Wi-Fi |
| Storage Media |
Removable SD card |
| Video Out |
DisplayPort over USB Type-C |
| METERLiNK |
Yes |
| ENVIRONMENTAL |
| Operating Temperature Range |
-15°C to 50°C (5°F to 122°F) |
| Safety |
EN/UL/CSA/PSE 60950-1 |
| Storage Temperature Range |
-40°C to 70°C (-40°F to 158°F) |
| Shock & Vibration & Encapsulation |
25 g (IEC 60068-2-27), 2 g (IEC 60068-2-6), IP 54 (IEC 60529) |
| IMAGING & OPTICAL |
| Color palettes |
Iron, Gray, Rainbow, Arctic, Lava, Rainbow HC |
| Detector Type and Pitch |
Uncooled microbolometer, 12 µm |
| Digital Camera |
5 MP, with built-in LED photo/video lamp |
| Digital Zoom |
1-8x continuous |
| f-number |
1.1 (42°lens), 1.3 (24° lens), 1.5 (14° lens) |
| Focus |
Continuous with laser distance meter (LDM), one-shot LDM, one-shot contrast, manual |
| Global Positioning System [GPS] |
Automatic image tagging |
| Image Frequency |
30 Hz |
| Image Sketch |
From touchscreen, on infrared image only |
| Lens Identification |
Automatic |
| Minimum Focus Distance |
42° lens - 0.15 m; 24° lens - 0.15 m, optional macro mode; 14° lens - 1.0 m |
| Non-Radiometric IR or Visual Video |
H.264 to memory card |
| Non-radiometric IR video streaming |
H.264 or MPEG-4 over Wi-Fi MJPEG over UVC or Wi-Fi |
| Picture-in-Picture |
Resizable and movable |
| Radiometric IR video recording |
Real-time radiometric recording (.csq) |
| Radiometric IR video streaming |
Yes, over UVC |
| Spectral Range |
7.5 - 14.0 µm |
| Viewfinder |
Yes |
| UltraMax |
Quadruples pixel count; activated in menu and processed in FLIR Tools |
| MEASUREMENT & ANALYSIS |
| Area measurement information |
Yes; calculates area inside measurement box in m² or ft² |
| Laser Distance Meter |
Yes; dedicated button |
| Measurement Presets |
No measurement, center spot, hot spot, cold spot, User Preset 1, User Preset 2 |
| Spot Meter |
3 ea. in live mode |
| METER DATA |
| Display |
4", 640 × 480 pixel touchscreen LCD with auto-rotation |
| POWER |
| Battery operating time |
Approx. 4 hours at 25°C (77°F) ambient temperature and typical use |
| Battery Type |
Li-ion battery, charged in camera or on separate charger |
| SHIPPING INFORMATION |
| Packaging |
Infrared camera with lens, small viewfinder eyecup, 2 batteries, battery charger, hard transport case, lanyards, front lens cap, power supplies, printed documentation, SD card (8 GB), cables (USB 2.0 A to USB Type-C, USB Type-C to HDMI, USB Type-C to USB Type-C) |
| STORAGE MEDIA |
| Image File Format |
Standard JPEG with measurement data included |
| Image Storage Mode |
Infrared, visual, MSX®, Picture-in-Picture |
