| Image and optical data |
| IR resolution |
1024 × 768 (786,432 pixels) |
| UltraMax® |
3.14 Mpixels |
| Field of view (FOV) |
12° × 9° (83 mm lens) |
| F-number |
f/1.2 (83 and 142 mm lenses) |
| Lens identification |
Automatic |
| Image frequency |
30 Hz |
| Focus |
One-shot, manual |
| Digital zoom |
1-8x continuous |
| Detector data |
| Detector type and pitch |
Uncooled microbolometer, 17 μm |
| Spectral range |
7.5 – 14.0 μm |
| Thermal sensitivity/NETD |
<25 mK @ 30°C (86°F) |
| Image presentation and modes |
| Display |
4.3", 800 × 480 pixel capacitive touch screen with auto-orientation |
| Viewfinder |
- |
| Digital camera |
5 MP with built-in LED |
| Color palettes |
Iron, Rainbow, Rainbow HC, White hot, Black hot, Arctic, Lava |
| Image modes |
Infrared, visual, MSX |
| Picture-in-picture |
- |
| Time-lapse (infrared) |
- |
| Measurement & analysis |
| Object temperature range |
40°C to 150°C (-40°F to 302°F), 0°C to 650°C (32°F to 1200°F) |
| Accuracy |
±2°C (±3.6°F) or ±2% of reading at 25°C (77°F) |
| Alarms |
- |
| Measurement function alarm |
- |
| Measurement & analysis |
| Compass, GPS |
- |
| METERLiNK® |
- |
| Measurement presets |
No measurement, center spot, hot spot, cold spot, User Preset 1, User Preset 2 |
| Spotmeter |
1 |
| Area |
1 box with max/min/avg |
| Laser pointer |
Dedicated button |
| Data storage and streaming |
| Storage media |
Removable SD card |
| Image file format |
Standard JPEG with measurement data included |
| Radiometric IR video recording |
- |
| Non-radiometric IR or visual video |
H.264 to memory card |
| Radiometric IR video streaming |
Yes, over USB |
| Non-radiometric ir video streaming |
H.264 over USB |
| Video out |
- |
| Additional features |
| Battery type |
Rechargeable Li-ion battery |
| Battery operating time |
Approx. 2.5 hours at 25°C (77°F) ambient temperature and typical use |
| Operating temperature range |
-15°C to 50°C (5°F to 122°F) |
| Storage temperature range |
-40°C to 70°C (-40°F to 158°F) |
| Shock/vibration/encapsulation; safety |
25 g / IEC 60068-2-29, 2 g / IEC 60068-2-6, IP 54 /IEC 60529; EN/UL/CSA/PSE 60950-1 |
| Tripod mounting |
UNC ¼"-20 |
| Weight/dimensions w/o lens |
2.1 kg (4.6 lbs), 16.7 × 20.5 × 18.8 cm (6.6 × 8.0 × 7.4 in) |
