| Detector Type |
Uncooled microbolometer |
| Encoding |
Video streaming – RTSP Protocol: H.264 / MPEG4 / MJPEG; GVSP: Uncompressed Radiometric streaming – RTSP Protocol: Compressed JPEG-LS, FLIR radiometric; GVSP: Uncompressed, signal linear, temperature linear, FLIR radiometric |
| FLIR Screen-EST Mode |
No |
| Size [L × W × H] |
123 × 77 × 77 mm (4.84 × 3.03 × 3.03 in) |
| Web interface |
Yes |
| Weight |
0.82 kg (1.8 lbs) |
| CONNECTIONS & COMMUNICATIONS |
| Connection Type |
Wi-Fi: Peer to peer (ad hoc) or infrastructure (network) |
| Connector |
Pan and tilt control: M8 A-coded, male; Wi-Fi: Female RP-SMA (Pan/Tilt is an optional feature) |
| Digital I/O connector type |
M12 Male 12-pin A-coded (shared with ext. power) |
| Digital Inputs |
2x opto-isolated, Vin (low) = 0 - 1.5 V, Vin (high) = 3-25V |
| Digital Output Purpose |
Programmatically set Fault (NC) |
| Digital Outputs |
3x opto-isolated, 0–48 VDC, max. 350 mA (derated to 200 mA at 60. Solid-state opto relay, 1x dedicated as Fault output (NC) |
| Ethernet Communication |
GigE Vision ver. 1.2, Client API GenICam compliant, TCP/IP socket-based FLIR proprietary |
| Ethernet Connector Type |
M12 8-pin X-coded, Female |
| Ethernet Image Streaming |
Yes |
| Ethernet Power |
Power over Ethernet, PoE IEEE 802.3af class 3 |
| Ethernet Protocols |
IEEE 1588, SNMP, TCP, UDP, SNTP, RTSP, RTP, HTTP, ICMP, IGMP, sftp (server), FTP (client) SMTP, DHCP, MDNS (Bonjour), uPnP |
| Multicast |
RTSP Protocol, GVSP (GigE Vision) Protocol |
| Serial Communication |
Pan and tilt control: RS232 and RS485 exclusively |
| Unicast |
RTSP Protocol, GVSP (GigE Vision) Protocol |
| WiFi |
Wi-Fi standard – IEEE802.11a/b/g/n |
| ENVIRONMENTAL |
| Encapsulation |
IP 54 (IEC 60529) IP66 with accessory |
| IMAGING & OPTICAL |
| Contrast Enhancement |
Histogram equalization (IR only) for RTSP and GVSP video streaming, Image Source 0 |
| Detector Pitch |
25 µm |
| Field of view (FOV) |
25° lens: 25° × 19° 6° lens: 6.4° × 4.9° |
| Focal Length |
25° lens: 18 mm 6° lens: 74 mm |
| Focal Plane Array (FPA) - Spectral range |
Uncooled microbolometer/7 – 8.5 µm |
| Focus |
One-shot contrast, motorized, manual |
| Gas Sensitivity [NECL] |
CH4 (<100 ppm × m), N2O (<75 ppm × m), C3H8 (<400 ppm × m), SO2 (<30 ppm x m); ΔT = 10°C, distance = 1 m |
| Image Frequency |
30 Hz |
| IR Resolution |
320 × 240 (76,800) pixels |
| Minimum Focus Distance |
0.3 m (0.98 ft) for 25° lens; 5 m (16.4 ft) for 6° lens |
| Overlay |
Image Source 0: RTSP Protocol: with, without; GVSP (GigE Vision) Protocol, with, without, |
| Spatial resolution (IFOV) |
1.4 mrad/pixel |
| Spectral Range |
7 – 8.5 µm |
| Thermal Resolution [NETD] |
<25 mk at 30°C (86°F) |
| Video Lamp |
Built-in LED light |
| Visual Resolution |
1280 × 960 pixels |
| MEASUREMENT & ANALYSIS |
| Accuracy |
±5°C (±9°F) for ambient temperature 15°C to 35°C (59°F to 95°F) and object temperature above 0°C (32°F) |
| Correction Options |
Atmospheric, optics transmission, emissivity, reflected apparent temperature, external optics/window |
| Measurement Corrections |
Global object parameters |
| Object Temperature Range |
–20°C to 70°C (–4°F to 158°F) |
| PAN-TILT |
| Pan/Tilt |
Optional feature; Control standard – Pelco D |
| POWER |
| External Voltage |
Allowed range 18-56 VDC, 8 W max |
| General |
PoE or external |
| Power Consumption |
6.8 W at 24 V DC typical 7.0 W at 48 V DC typical 7.3 W at 48 V PoE typical |
| THERMAL CAMERA |
| Visual Focus and FOV |
Fixed, 67.2° diagonal |
