FLIR DM62-NIST - TRMS Digital Multimeter with Non-Contact Voltage and NIST

A built-in 80 x 60 resolution thermal camera sensor visually guides you to an electrical problem
Includes True RMS, VFD mode, and more
Comes with high-quality test leads and a Type K thermocouple input (DM166 and DM64)
Intuitive user interface and high-quality design, with flashing backlight and audible indicators
Drop-tested, with a CAT IV-300 V, CAT III-600 V safety category rating

The DM62 and DM66 digital multimeters combine a rich feature set, precise measurements, and quality construction into tools of exceptional value. The meters are easy to use and built to last, offering long term stability for everyday use. The DM62 offers the accuracy and range of measurement options you need, whether you’re a professional or just need the right tool for DIY.

The DM66 has all the great features of the DM62 plus the added benefit of low impedance (LoZ) mode to prevent ghost voltage from delivering false readings. It measures frequency, diode, capacitance, and temperature, for a comprehensive feature set ideal for commercial electricians, automation field service, or electronics repair technicians.

Whichever one you choose, you’ll get the job done fast and efficiently.

The DM62 has essential measurement features including True RMS AC/DC voltage and current, non-contact voltage detection, VFD mode, and extended voltage measurement range up to 600 V. Whether you're a commercial electrician, electronics technician, or just need the right tool for DIY, the DM62 provides precise measurements and quality construction for everyday use.

FLIR DM62 Specifications
Continuity Check	30Ω and 480Ω
Measuring Rate	5 samples per second
Safety Category Rating	CAT IV-300V, CAT III-600V
IP Rating	IP40
Electrical Specifications
AC/DC Volts	Range: 600.0V
AC/DC Volts	Accuracy: ±1.0%/0.4%
AC/DC mVolts	Range: 600.0mV
AC/DC mVolts	Accuracy: ±1%/0.4%
AC/DC Amps	Range: 10.00A
AC/DC Amps	Accuracy: ±1.5%/1.0%
AC/DC mAmps	Range: 600.0mA
AC/DC mAmps	Accuracy: ±1.0%/0.7%

FLIR DM62/DM64/DM66/DM166 General Specifications
Model Number	FLIR DM166	FLIR DM66	DM64	DM62
Thermal Imaging
IR Resolution	60 × 80 pixels (4,800 pixels)	–	–	–
Thermal Image Palettes	Rainbow, iron, gray scale	–	–	–
Temperature Range	–10 to 150°C (14 to 302°F)	–	–	–
Focus	Fixed	–	–	–
Electrical Measurements
True RMS	Yes
	Range	Basic Accuracy	Range	Basic Accuracy
AC / DC Voltage	600.0 V	±0.7% / ±0.5%	600.0 V	±1.0% / ±0.4%
AC / DC mVolt	600.0 mV	±1% / ±0.5%
VFD AC Voltage	600.0 V RMS	±1.0%	600.0 V RMS	±1.0%
AC / DC Amperage	10.00 A	±1.0% / ±0.7%	10.00 A	±1.5% / ±1.0%
AC / DC mAmp	600.0 mA	±1.0% / ±0.7%
AC / DC µAmp	4000 µA	±1.5%
Resistance	600.0 Ω 600.0 kΩ 6.000 MΩ 60.00 MΩ	±0.3% ±0.5% ±0.9% ±1.5%	6.00 kΩ 600.0 kΩ 60.00 MΩ	±0.3% ±0.5% ±0.9%
Capacitance*	200.0 nF 200.0 µF 2.000 mF 10.00 mF	±1.5% ±1.5% ±2.0% ±5.0%	200.0 nF 2000 µF 10.00 mF	±1.5% ±1.5% ±4.5%
AC / DC LoZ V*			600.0 V	±2.0%
Diode Test	3.000 V	±0.9%	3.000 V	±0.9%
Frequency Range	99.99 kHz	± 1.0%	99.99 kHz	± 1.0%
Continuity Check	Between 30 Ω and 480 Ω
Thermocouple	–40 to 752.0°F DMM ± (1.0% + 3°F), –40 to 400°C DMM ± (1.0% + 1.5°C)
Additional Data
Safety Category Rating	IEC 61010-1, CAT III-600V, CAT IV-300V
IP Rating	IP40
Auto Power Off	Yes
Drop Test	3 m	2 m
Warranty	10 yrs on product and detector		Limited lifetime warranty

Multimeters Template
Style	Hand-Held
Measures AC V	Yes
Measures DC V	Yes
Measures AC A	Yes
Measures DC A	Yes
True RMS	Yes
Maximum Voltage AC	600 V
Maximum Voltage DC	600 V
Maximum Current AC	10 A
Minimum Current AC	600 mA
Maximum Current DC	10 A
Minimum Current DC	600 mA
# Digit Display	3.5
Backlight	Yes
Resistance	Yes
Frequency	No
Diode Testing	Yes
CAT Rating	IV
CAT Voltage	300 V, 600 V CAT Voltage CAT IV-300V, CAT III-600V
Peak Hold	Yes
Data Hold	Yes
Test Equipment General Attributes
Unique Features	Electrical and Field Service TRMS Multimeter with VFD mode
Warranty Details	Limited lifetime warranty
IP Rating	IP40
Product Weight	11.8 OUNCES (0.738 LBS)
Product Height	2 IN
Product Length	6.3 IN
Product Width	3.2 IN
Shipping Weight	3 LBS
Battery Type	AAA
Power Supply Voltage	Battery Powered Power Supply Voltage 2 AAA batteries
Country of Origin	Taiwan
Shipping Height	13 IN
Shipping Length	4.3 IN
Shipping Width	5.5 IN
