| General |
| DC Loop | Current %4 to 20mA - 4mA = 0% (zero), 20mA = 100% (span), Resolution - 0.01%, Accuracy - ±25d |
| Diode Test | Accuracy - 1%+1d, Current 0.8mA(typical), Open circuit - <3.5VDC |
| Peak Capture (Instantaneous Peak Hold) | Accuracy - Specified accuracy ±100 digits for changes > 0.8ms in duration |
| Audible Continuity | Measurement threshold - Between 20 Ω and 200 Ω, response time - <100 μs |
| Accuracy Notes | Accuracy is ± (% reading + number of digits), or as otherwise specified, at 23 °C ±5 °C < 75% R.H. True RMS accuracies are specified from 5% to 100% of range or as otherwise specified. |
| Maximum Crest Factor | <5:1 at full scale & <10:1 at half scale with frequency component within the specified frequency bandwidth for non-sinusoidal waveforms. |
| Sensing | DC, AC True RMS, AC+DC True RMS |
| Digital Display | 4-4/5 digits, 50000 count 5-4/5 digits, 500000 count for DCV 6 digits, 999999 count for Hz |
| Bar Graph Display | 42-segment bargraph |
| Polarity | Automatic |
| Update rate | 5 /second for 50,000 count display (fast mode), 1.25/second for 500,000 count display (stable mode), 60 per second for bar graph display |
| Low Battery | Below approx. 7V |
| Operating Temperature | 41° to 104 °F (5° to 40°C) |
| Storage Temperature | -4° to 140°F (-20 to 60°C) |
| Relative Humidity | Max 80% up to 87°F (31°C) decreasing linearly to 50% at 104°F(40°C), <80% storage |
| Operating Altitude | Below 2000 meters |
| Temp. Coefficient | Nominal 0.1x(specified accuracy)/°C at(0°C to 18°C or 28°C to 40°C), or otherwise specified |
| Power Supply | 9V battery (NEDA1604, JIS006P or IEC6F22) |
| Power Consumption | 5mA typical |
| Auto Power Off | After 17 minutes of inactivity with no input signal. |
| Power consumption during auto power off | 20 μA |
| Safety | The MultiMaster Series meters are intended for indoor use and are protected, against the users, by double insulation per EN61010-1 and IEC61010-1 2nd Edition (2001) to CAT III 1000V & CAT IV 600V. The meter (all versions) also meets UL3111-1(1994) and CSA C22.2 No. 1010-1-92 to CAT III 1000V. |
| Dimension | 7.32 x 3.43 x 1.4" with holster (186mm x 87mm x 35.5mm) |
| Weight | 15.17 oz. with holster (430g) |
