| General Specifications |
| Display |
Large 5 digit multifunction LCD |
| Output (source) |
Ranges, Resolution, and Accuracy |
| DC Current |
4 to 20.000mA, 0 to 20.000mA, 0 to 24.000mA |
| Accuracy for all mA ranges |
± (0.025% + 3 digits) |
| DC Voltage |
0 to 100.00mV, 0 to 1.0000V, 0 to 12.000V |
| Accuracy for all voltage ranges |
± (0.05% + 3 digits) |
| Type K Temperature |
-328 to 32°F (-200 to 0°C) |
| Accuracy |
± 2.0°F (1.1°C), 32 to 2400°F (0 to 1300°C); |
| Type J Temperature |
-148 to 32°F (-100 to 0°C) |
| Accuracy |
± 1.6°F (0.9°C) , 32 to 1400°F (0 to 760°C) |
| Type E Temperature |
-148 to 32°F (-100 to 0°C) |
| Accuracy |
± 1.6°F (0.9°C), 32 to 1292°F (0 to 700°C) |
| Type T Temperature |
-328 to 32°F (-200 to 0°C) |
| Accuracy |
± 1.8°F (1.0°C), 32 to 752°F (0 to 400°C) |
| Frequency |
1 to 125 Hz, 126 Hz to 62,500 Hz |
| Accuracy |
± 0.04Hz, Accuracy notes All published accuracies are 'of reading'. Meter must be warmed up for 20 minutes before use for optimum accuracy. |
| Power supply |
9V battery, external battery pack (6 x 1.5V 'AA'), or optional AC adapter |
| Power Consumption |
60 to 180mA |
| Operating Conditions |
32 to 122°F (0 to 50°C), 85% RH max. |
| Storage Conditions |
-4 to 140°F (-20 to 60°C), 85% RH max. |
| Dimensions |
3.46 x 6.61 x 1.03" (88 x 168 x 26mm) |
| Weight |
11.63 oz. (330g) |
| Accessories |
Test leads (banana to alligator clip type), carrying case, 9V battery, battery-pack with six 1.5V AA batteries, and two temperature cables (Type-K & Type J; sub-miniature to sub-miniature connector type). |
