Extech 38390-NIST 400A AC Mini Clamp Meter

Name: Extech 38390-NIST 400A AC Mini Clamp Meter
Brand: Extech
SKU: Extech38390-NIST
Availability: InStock

0 reviews | Model: Extech 38390-NIST

Compare

CLAMP METER, MINI W/NIST 38390 - PLEASE NOTE: If not in stock: NIST calibration takes between 7-14 days once stock is available.

View Product Details

List Price: $139.00

In Stock:

Recommended for you

AC Current
Range	40.00A, 400.0A
Accuracy	± (2% + 15 digits)
Remarks	Frequency - 50/60Hz, 660A overload protection
AC Voltage
Range	400.0V, 600V
Accuracy	± (1.5% + 10 digits)
Remarks	Frequency - 40Hz to 450Hz, Input Z- 1M Omega;660Vrms OL protect
DC Voltage
Range	400.0V, 600V
Accuracy	± (1% + 5 digits)
Remarks	Input Z - 1M Ω 660V overload protect
Resistance
Range	0.3 to 400 Ω
Accuracy	± (1% + 5 digits)
Remarks	-1.1 to -1.3V open circuit, 600Vrms overload protect
Continuity Audible tone
Range	<40 Ω approximately -1.1 to -1.3V open circuit
Remarks	600Vrms overload protect
General
Conductor Size	0.9" (23mm ) maximum
Operating principle	Dual slope integration
Battery type	2 x 1.55V button (ICE LR-44, NEDA 116A or A76)
Battery Life	200 hours
Auto Power off	After 30 minutes
Range Selection	Automatic ranging
Display	3-3/4 digit (3999 Count) LCD
Overload Indication	"OL"
Low Battery Indication	Battery icon
Environmental conditions	Installation Category II,Pollution degree 2,Altitude up to 2000 meters, Indoor use only
Operating Temperature/Humidity	32 to 104F (0°C to 40°C) / <80% RH
Storage Temperature/Humidity	14 to 140F (-10°C to 60°C) / <70% RH
Dimensions	7.4 x 2.5 x 1.2” (188 x 62.5 x 30.5mm)
Weight	6.5 oz. (185g)
