Extech 42510A Mini IR Thermometer

Name: Extech 42510A Mini IR Thermometer
Brand: Extech
SKU: Extech42510A
Price: 102.79 USD
Availability: InStock
Rating: 5.00 (2 reviews)

5 (2 Reviews) | UPC: 793950426104 | Model: Extech 42510A

Compare

IR Thermometer, Mini, Wide Temp, 1000F/538C

IR Temperature range: -58 to 1200°F (-50 to 650°C)
High resolution of 0.1° up to 199.9°
High/Low setpoints with audible alarm
0.10 to 1.00 adjustable emissivity for better accuracy on different surfaces
Built-in laser pointer for easy targeting
Large backlit LCD display
Data Hold and Min/Max, overrange indicator, auto power off
Complete with 9V battery and pouch case

View Product Details

List Price: $115.49

Your Price: $102.79

Sign-in for EDU Pricing!

In Stock:

Free shipping over $99 - Code: FREESHIP
Please note, FREE SHIPPING is only available on items that can ship via standard ground shipping and is only valid within the Contiguous United States. Any items that must ship via freight or to any destination outside of the Contiguous United States will be excluded. - USE CODE FREESHIP at checkout

Valid on Web Price Only!
View Payment Options

Request Quote

Items in This Series



Product	Extech 42510A IR Thermometer, Mini, Wide Temp, 1000F/538C	Extech 42510A-NIST IR Thermometer W/NIST 42510- PLEASE NOTE: If not in stock: NIST calibra ...
Price
In Stock
IR Temperature Max	1200 F	200 F
IR Temperature Min	-58 F	-50 F
Field View Ratio (Spot Ratio)	12:1	12:1
Compare	Add to compare	Add to compare

Recommended for you

1200°F (650C) 12:1 Laser IR Thermometer

Compact thermometer measures temperature from -58 to 1200°F (-50 to 650°C) with 0.1° resolution for readings up to 999.9°. Adjustable High/Low setpoints with audible alarm alerts user when temperature exceeds the programmed setpoints.

Additional Features

Adjustable emissivity provides more accurate readings on reflective surfaces. Built-in laser pointer identifies target area. Backlighting illuminates display for taking measurements at night or in areas with low background light levels. Data Hold and Min/Max. Overrange indicator and Auto power off.

Infrared Thermometer Specifications
Range / Resolution	-58 to 200°F (-50 to 200°C), 200°F to 1400°F (200°C to 760°C)
Accuracy	± 2% of reading or ± 4°F (2°C) whichever is greater.
Note	Accuracy is specified for the following ambient temperature range: 64 to 82°F (18 to 28°C)
Emissivity	0.95 fixed value
Field of View	D/S = Approx. 12:1 ratio (D = distance; S = spot)
Laser power	Less than 1mW
Spectral response	6 to 14 µm (wavelength)
General Specifications
Display	Backlit LCD display with function indicators
Display update rate	1 second approx.
Operating Temperature	32°F to 122°F (0°C to 50°C)
Operating Humidity	Max. 80% RH.
Power Supply	9V battery
Automatic Power Off	Meter shuts off automatically after 6 seconds
Weight	6.4 oz. / 180g
Dimensions	3.2 x 1.6 x 6.3” (82 x 42 x 160mm)

Thermometers/IR Thermometers Template
IR Temperature Max	1200 F
IR Temperature Min	-58 F
Field View Ratio (Spot Ratio)	12:1
Accuracy	-50°C to -35°C (-58°F to -31°F): ±4°C/9°F -35°C to -2°C (-31°F to 28°F): ±3°C/5°F -2°C to 94°C (28°F to 200°F): ±2.5°C/3°F 94°C to 204°C (200°F to 400°F): ±(1.0%rdg + 1°C/2°F) 204°C to 426°C (400°F to 800°F): ±(1.5%rdg + 1°C/2°F) 426°C to 650°C (800°F to 1200°F): ±(2.0%rdg +1°C/2°F) Note: Accuracy is specified for the following ambient temperature range: 18 to 28°C (64 to 82°F)
Laser Pointer	Yes
Backlight	Yes
Emissivity Adjustable	Yes
Alarm	Yes
Data Hold	Yes
Max./Min.	Yes
Memory Recall	No
Thermocouple Input	No
Food Safe	No
Test Equipment General Attributes
Unique Features	-IR Temperature range: -58 to 1200°F (-50 to 650°C) -High resolution of 0.1° up to 199.9° -High/Low setpoints with audible alarm 0.10 to 1.00 adjustable emissivity for better accuracy on different surfaces -Built-in laser pointer for easy targeting -Large backlit LCD display -Data Hold and Min/Max, overrange indicator, auto power off
Warranty	1 YEARS
Safety Approval	CE
Product Weight	180 GRAMS (0.397 LBS)
Product Height	160 MM (6.30 IN)
Product Length	82 MM (3.23 IN)
Product Width	42 MM (1.65 IN)
Shipping Weight	1 LBS
Data Logging	No
HTS/Schedule B Number	9025.19.8085
ECCN Number	EAR99
Calibration Included	Factory Calibration
Battery Type	9v
Power Supply Voltage	Battery Powered
Country of Origin	China
Shipping Height	2.70 IN
Shipping Length	10.50 IN
Shipping Width	6.60 IN
