Extech 412300A-NIST Milliamp Calibrators - Current Measurement Max: 50 mA, Current Measurement Min: 0 mA, Source/Simulate DC Current: No

Name: Extech 412300A-NIST Milliamp Calibrators - Current Measurement Max: 50 mA, Current Measurement Min: 0 mA, Source/Simulate DC Current: No
Brand: Extech
SKU: Extech412300A-NIST
Price: 354.99 USD
Availability: InStock

0 reviews | UPC: 793950423103 | Model: Extech 412300A-NIST

Compare

Calibrator W/ NIST 412300A- PLEASE NOTE: If not in stock: NIST calibration takes between 7-14 days once stock is available.

Upgraded models now feature super large LCD display and touch keypad
LCD displays readings in mA or as a % of the 0 to 24mA range or as mV in voltage ranges
Five stored calibration values for fast calibrations
412355A Current + Voltage Calibrator provides adjustable 0 to 24mA and 0 to 20V calibration source
412300A Current Calibrator provides 0 to 24mA output displayed as mA or % and provides 24VDC power to measure a two-wire current loop
Complete with 9V battery,calibration cable with spade lug terminals,carrying case,and 100V-240V AC Universal Adaptor (50/60Hz)

Applications:

Setup and calibration of process devices such as transducers,indicators,recorders and controllers
Troubleshooting and Field service
Product design

View Product Details

List Price: $354.99

In Stock:

View Payment Options

Recommended for you

Current Calibrator/Meter with NIST Certificate

The Model 412300A Current Calibrator can measure and source current. It also has 12VDC loop power for powering and measuring simultaneously. The Model 412355A can measure and source current and voltage. The Oyster Series meters have a convenient flip up display with neck-strap for hands-free operation. With proper care this meter will provide years of safe, reliable service.

General Specifications
Display	3 1/2 digit LCD (2000 counts, displays 0 to 1999)
Accuracy (of reading)	± (0.075% + 1 digit) or ± 3 digits, Whichever is greater
Meter Power	9 volt battery or AC adaptor
Loop Power	12V DC (412300A only)
Maximum Load	350 ohms at 20 mA
Dimensions	3.8 x 4.2 x 1.8" (96 x 108 x 45mm) folded
Weight	12 oz. (340g)
Accessories Supplied	9V battery, calibration cable with spade lugs, carrying case, 110V AC adaptor
Optional Accessories	220/240V AC Adaptors, NIST Certificate
Range Specifications
Measurement range (resolution)	0 to 50mA, 0 to 19.99V (412355A only)
Output ranges (resolution)	0 to 24.0mA (upto 1000 ohms), -25% to +125% (0.1%)

Tech Specs

Process / Calibration/Milliamp Calibrators Template
Current Measurement Max	50 mA
Current Measurement Min	0 mA
Source/Simulate DC Current	No
Measure DC Current	No
Two Wire Transmitter Simulation	No
Percent Display	No
Resolution AC Current	0.1 mA (0.0001 A)
Accuracy	0.075% ±1 digit
Simulate Loop Voltage	No
Backlight	No
Ramp/Step Output	No
FieldBus Compatible	No
Process / Calibration/Signal Calibrators/Loop Calibrators Template
Hart Compatible	No
Intrinsically Safe	No
Test Equipment General Attributes
Unique Features	24VDC drives current loads up to 1000O Five preset calibration values for fast calibration High accuracy 0.075% Oyster case with flip-up display is ideal for handheld or benchtop applications Large LCD displays readings in mA (to 0.01mA) or as a percentage of the 0-24mA range (4-20mA = 0-100.0%) or as mV in voltage ranges
Warranty	1 YEARS
Safety Approval	CE
Product Weight	12 OUNCES (0.75 LBS) Product Weight 340gr.
Product Height	1.8 IN
Product Length	3.8 IN Product Length (96x108x45mm) folded
Product Width	4.2 IN
Data Logging	No
ECCN Number	EAR99
Calibration Included	NIST Calibration
Battery Type	9v
Power Supply Voltage	120V/220V Universal, Battery Powered
Country of Origin	Taiwan
