Extech 380562-OB Milli-Ohmmeter - Style (Milli-Ohmmeter): Bench, Line Power or Battery power: Line Power, Minimum Resistance: 0.01 m Ohms

Name: Extech 380562-OB Milli-Ohmmeter - Style (Milli-Ohmmeter): Bench, Line Power or Battery power: Line Power, Minimum Resistance: 0.01 m Ohms
Brand: Extech
SKU: Extech380562-OB
Price: 515.66 USD
Availability: InStock

0 reviews | UPC: 793950385623 | Model: Extech 380562-OB

Compare

Milliohm Meter 220 VAC - This open box item may be missing original packaging, missing some small accessories or a lightly used demo unit.

This open box item may be missing original packaging, missing some small accessories or a lightly used demo unit.
7 ranges for wide low resistance measurements
High resolution to 0.01m
1999 count display with 0.8" digits
Automatic zero
Built-in comparator for Hi/Lo/Go resistance testing or selection
5V test voltage
One year warranty

View Product Details

List Price: $579.00

In Stock:

View Payment Options

Recommended for you

Accessories

Choose a Category

Misc Test Leads

for the Extech 380562-OB

Extech 380465 Test Leads For 380460

Catalog: 380465

(3)

In Stock!

Add to Cart

Extech 380562 High Resolution Precision Milliohm Meter (220VAC)

High resolution to 0.01m
5V test voltage
Built-in comparator for Hi/Lo/Go
1999 count display with 0.8" digits
Resistance testing or selection

Benchtop meter provides resolution down to 0.01mΩ

The 380562 Compact and precise, the Extech 380562 Milliohm Meter has 7 ranges and measures down to 0.01mΩ using 4-wire Kelvin clip test leads. Measurements are displayed on the unit's large 0.8", 1999-count LCD. Built-in comparator for Hi/Lo/Go resistance testing or selection. Complete with 4-wire cables with Kelvin clip connectors and power cord.

General Specification
---	Range	Resolution	Current	Accuracy (%rdg)
Resistance	20mΩ	0.01mΩ	1A	±(0.2% + 6d)
	200mΩ	0.1mΩ	1A	±(0.2% + 4d)
	2Ω	0.001Ω	100mA	±(0.2% + 4d)
	20Ω	0.01Ω	10mA	±(0.2% + 4d)
	200Ω	0.1Ω	1mA	±(0.2% + 4d)
	20kΩ	0.001kΩ	100μA	±(0.2% + 4d)
	2kΩ	0.1kΩ	10μA	±(0.2% + 4d)
Power	110VAC, 60Hz or 220VAC 50Hz
Dimensions/Weight	11 x 8.3 x 3.5" (280 x 210 x 90mm)/ 4.85lb (2.2kg)

Tech Specs

Micro / Milli / Meg Ohmmeters/Milli-Ohmmeter Template
Style (Milli-Ohmmeter)	Bench
Line Power or Battery power	Line Power
Minimum Resistance	0.01 m Ohms (0.00001 Ohms)
Maximum Resistance	20 K Ohms (20000 Ohms)
Max Resolution (Ohms)	0.01 m Ohms (0.00001 Ohms)
Variable Test Current	Yes
Maximum Current	1 A
Minimum Current	10 uA
Selectable Ranges	Yes
Alarm	No
Comparator Function	Yes
Digits Display	6
Kelvin Four-Terminal Measurement	Yes
General Attributes
Warranty	1 YEARS
Product Weight	4.85 LBS Product Weight 2.2kg
Product Height	8 IN
Product Length	3.5 IN Product Length 280 x 210 x 90mm
Product Width	11 IN
Country of Origin	Taiwan
Test Equipment General Attributes
Unique Features	7 ranges for wide 20.00mO to 20.00kO low resistance measurements High resolution to 0.01mO 1999 count display with large 0.8" digits 4-wire test cable with Kelvin clip connectors Automatic zero Built-in comparator for Hi/Lo/Go resistance testing or selection Complete with 4-wire cables with Kelvin clip connectors and power cord
Safety Approval	CE
Data Logging	No
HTS/Schedule B Number	9030.33.3400
ECCN Number	EAR99
Calibration Included	None
Power Supply Voltage	220V Only
