Extech 380562-NIST - High Resolution Precision Milliohm Meter (220VAC)

0 reviews | UPC: 793950385630 | Model: Extech 380562-NIST

Extech 380562-NIST

Compare

Milliohm Meter w/NIST, 380562- <span style="color:gray;">PLEASE NOTE: If not in stock: NIST calibration takes between 7-14 days once stock is available.</span>

7 ranges for wide low resistance measurements
High resolution to 0.01mOhm
1999 count display with 0.8" digits
4-wire test cable with Kelvin clip connectors
Automatic zero
Built-in comparator for Hi/Lo/Go resistance testing or selection
Limited Two Years Warranty

View Product Details

List Price: $709.00

In Stock:

View Payment Options

Recommended for you

Accessories

Choose a Category

Misc Test Leads

for the Extech 380562-NIST

Extech 380465 Test Leads For 380460

Catalog: 380465

(3)

In Stock!

Add to Cart

Extech 380562-NIST

Automatic zero
5V test voltage
High resolution to 0.01m
1999 count display with 0.8" digits

High Resolution Precision Milliohm Meter (220VAC)

Benchtop meter provides resolution down to 0.01mΩ

Compact and precise, the Extech 380562 Milliohm Meter has 7 ranges and measures down to 0.01mΩ using 4-wire Kelvin clip test leads. Measurements are displayed on the unit's large 0.8", 1999-count LCD. Built-in comparator for Hi/Lo/Go resistance testing or selection.

Hioki - RM3548

General Specification
---	Range	Resolution	Current	Accuracy (%rdg)
Resistance	20mΩ	0.01mΩ	1A	±(0.2% + 6d)
	200mΩ	0.1mΩ	1A	±(0.2% + 4d)
	2Ω	0.001Ω	100mA	±(0.2% + 4d)
	20Ω	0.01Ω	10mA	±(0.2% + 4d)
	200Ω	0.1Ω	1mA	±(0.2% + 4d)
	20kΩ	0.001kΩ	100μA	±(0.2% + 4d)
	2kΩ	0.1kΩ	10μA	±(0.2% + 4d)
Power	110VAC, 60Hz or 220VAC 50Hz
Dimensions/Weight	11 x 8.3 x 3.5" (280 x 210 x 90mm)/ 4.85lb (2.2kg)

Tech Specs

Micro / Milli / Meg Ohmmeters/Milli-Ohmmeter Template
Style (Milli-Ohmmeter)	Bench
Line Power or Battery power	Line Power
Minimum Resistance	0.01 m Ohms (0.00001 Ohms)
Maximum Resistance	20 K Ohms (20000 Ohms)
Max Resolution (Ohms)	0.01 m Ohms (0.00001 Ohms)
Variable Test Current	Yes
Maximum Current	1 A
Minimum Current	10 uA
Selectable Ranges	Yes
Alarm	No
Comparator Function	Yes
Digits Display	6
Kelvin Four-Terminal Measurement	Yes
Test Equipment General Attributes
Unique Features	7 ranges for wide 20.00mO to 20.00kO low resistance measurements High resolution to 0.01mO 1999 count display with large 0.8" digits 4-wire test cable with Kelvin clip connectors Automatic zero Built-in comparator for Hi/Lo/Go resistance testing or selection Complete with 4-wire cables with Kelvin clip connectors and power cord
Warranty	2 YEARS
Warranty Details	Limited Two Years Warranty
Safety Approval	CE
Product Weight	4.85 LBS Product Weight 2.2kg
Product Height	8 IN
Product Length	3.5 IN Product Length 280 x 210 x 90mm
Product Width	11 IN
Data Logging	No
HTS/Schedule B Number	9030.33.3400
ECCN Number	EAR99
Calibration Included	NIST Calibration
Power Supply Voltage	220V Only
Country of Origin	Taiwan
