Enerpac SG18TESTD - Hydraulic Secure-Grip In-Line Flange Spreader Set, 20.2 Ton, 3.90" Maximum Spread

Name: Enerpac SG18TESTD - Hydraulic Secure-Grip In-Line Flange Spreader Set, 20.2 Ton, 3.90" Maximum Spread
Brand: Enerpac
SKU: EnerpacSG18TESTD
Price: 11090.00 USD
Availability: InStock

0 reviews | UPC: 662005410927 | Model: Enerpac SG18TESTD

Compare

Flange Spreader Set, 20.2 Ton, 3.90" Maximum Spread

Capacity (tons): 20.2
Maximum Spread (in): 3.90
Power source: Hydraulic
Applicable for larger-sized flanges
Actuated by an external hand pump
Suitable for bolt holes from 2.34 to 4.25 inches

View Product Details

Available Options

Your Price: $11,090.00

In Stock:

View Payment Options

Request Quote

Non-Cancellable / Non-Returnable

Items in This Series



Product	Enerpac SG18TESTD Flange Spreader Set, 20.2 Ton, 3.90" Maximum Spread	Enerpac SG4TMSTD Flange Spreader Set, 4.2 Ton, 2.95" Maximum Spread	Enerpac SG6TMSTD Flange Spreader Set, 6.7 Ton, 3.15" Maximum Spread	Enerpac SG11TMSTD Flange Spreader Set, 12.3 Ton, 3.54" Maximum Spread	Enerpac SG13TESTD Flange Spreader Set, 14.6 Ton, 4.53" Maximum Spread	Enerpac SG15TESTD Flange Spreader Set, 16.9 Ton, 3.94" Maximum Spread	Enerpac SG25TESTD Flange Spreader Set, 28.1 Ton, 4.72" Maximum Spread
Price
In Stock
Type (Tools)	Other	Other	Other	Other	Other	Other	Other
Compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare

Recommended for you

Enerpac SG18TESTD - Hydraulic Secure-Grip In-Line Flange Spreader Set, 20.2 Ton, 3.90" Maximum Spread

The SG18TE In-line secure grip bolt-hole spreader can be used on all flange types with bolt-hole sizes ranging from 2.34" (59.5mm) to 2.95" (75mm). This high-end, hydraulic model offers up to 20.2 imperial tons (180 kN) of spreading force. Spreading force of 40.5 imperial tons (350 kN) if used in pairs as recommended.

SG Flange Spreaders Series Comparison Table

Model	Maximum Spread (in)	Power Source	Maximum Operating Torque (Ft.lbs)	Capacity (imperial tons)	Usable on Flanges Specified to Accept the Following Bolt Sizes
SG4TMSTD	2.95	Mechanical	35	4.2	M16, M20, 5/8”, 3/4”
SG6TMSTD	3.15	Mechanical	80	6.7	M24, M27, 7/8”, 1”
SG11TMSTD	3.54	Mechanical	89	12.3	M30, M33, M36, 1 1/8”, 1 1/4”, 1 3/8”
SG13TESTD	4.53	Hydraulic	-	14.6	M39 (1 1/2”), M42 (1 5/8”), M45 (1 3/4”)
SG15TESTD	3.94	Hydraulic	-	16.9	M48 (1 7/8”), M52 (2”), M56 (2 1/4”)
SG18TESTD	3.9	Hydraulic	-	20.2	M60 (2 3/8”), M64 (2 1/2”), M70 (2 3/4”)
SG25TESTD	4.72	Hydraulic	-	28.1	M76 (3”), M80 (3 1/4”), M84 (3 3/8”), M90 (3 1/2”), M95 (3 3/4”), M100 (4”)

(1) SG18TE Tool c/w Hydraulic Cylinder
(1) Spreading Plug
(1) 10,000 psi (700 bar) HP550S Sealed Hand Pump with Gauge
(1) 10,000 psi (700 bar) Hydraulic Hose, 78.7" (2m)
(1) 12" (300mm) Vernier Calliper
(1) 0.5" (12.5mm) Spacer Plate
(1) 5mm Allen Key
(1) 2.0" (50mm) Spacer
(1) Safety Block
(2) M60 (2 3/8") Collets
(2) M64 (2 1/2") Collets
(2) M70 (2 3/4") Collets
(1) Instruction Manual
(1) Carry Case with Protective foam inserts

Tools/Other Hand Tools Template
Type (Tools)	Other
Test Equipment General Attributes
Warranty Details	Warranted for so long as it is owned by the first-using purchaser.
Product Weight	99.2 LBS
Product Height	35 IN
Product Length	22.4 IN
Product Width	6.5 IN
Shipping Weight	114.08 LBS
UPC	662005410927
