| Image pick-up device |
1/2.3" CMOS sensor 3,400,000 pixels |
| Effective pixels |
3264 (H) x 2,244 (V) |
| Frame rate |
30 fps |
| Resolution |
Analog RGB: 800 (H) x 800 (V) TV lines or more |
| Zoom |
Powered, 12x optical |
| Lens |
F3.2-3.6, f=4.0 mm- 48.0 mm |
| Shooting area |
1080p: Max. 16 9/16" x 9 3/16" (420 x 233 mm) Min. 1 15/16" x 1 1/16" (48.5 x 27.5 mm)
720p: Max. 16 9/16" x 9 3/16" (420 x 233 mm) Min. 1 15/16" x 1 1/16" (48.5 x 27.5 mm)
SXGA: Max. 16 9/16" x 13 1/8" (420 x 334 mm) Min. 1 15/16" x 1 1/2" (48.5 x 38.5 mm)
WXGA: Max. 16 9/16" x 10 3/16" (420 x 259 mm) Min. 1 15/16" x 1 3/16" (48.5 x 30.5 mm)
XGA: Max. 16 9/16" x 12 5/16" (420 x 313 mm) Min. 1 15/16" x 1 7/16" (48.5 x 36.5 mm) |
| Focus |
One-push Auto / Zoom Sync |
| White balance |
Auto / Cloudy / Sunny / Fluorescent light / Incandescent light / Shade / Twilight / Fluorescent light (warm color) |
| Image mode |
Text1 / Text2 / Text3 / Graphics1 / Graphics2 |
| Edge enhancement |
Provided (only for graphics mode) |
| Pause |
Provided |
| Still image storage |
Provided |
| Movie storage |
Provided |
| USB image output |
Provided (ELMO original, UVC (USB Video Class)) |
| Digital zoom |
16x |
| Gamma setting |
Provided (only for graphics mode) |
| Graphical OSD (On-Screen Display) |
rovided |
| Slide show |
Provided (image data) |
| Image save |
SD memory card / SDHC memory card / USB flash drive |
| State presetting |
Up to 3 user settings |
| Annotation |
Provided (CRA-1 use) |
| Brightness control |
Manual |
| Support functions |
Highlight, Mask, Scroll (in digital zoom), Mosaic, Split screen, PinP (Picture-in-Picture), Color filter, Microscope, Image rotation (0º/180º), Positive/negative conversion, Color/B&W selection |
| Input selection |
Main / External |
| Output terminals |
RGB output mini D-sub 15-pin connector, female x 1
HDMI output terminal x 1
Line Out terminal 3.5 mm-diameter stereo mini jack x 1 |
| Input terminals |
RGB input mini D-sub 15-pin connector, female x 1
HDMI imput terminal x1
Mic In/Line In terminal (shared), 3.5 mm-diameter stereo mini jack x1 |
| Ext. control terminal |
USB device (2.0 compliant) (UVC Compliant) Mini-B receptacle x 1 |
| Analog RGB output |
1080p: 1,920 x 1,080 @ 60 Hz
720p: 1,280 x 720 @ 60 Hz
SXGA: 1,280 x 1,024 @ 60 Hz
WXGA: 1,280 x 800 @ 60 Hz
XGA: 1,024 x 768 @ 60 Hz |
| HDMI output |
Image output: 1080p/720p
Audio output: PCM 44.1 kHz sampling frequency |
| Memory interface |
SD memory card slot x 1, USB host (2.0 compliant) Type A receptacle x 1 |
| Illumination lamp |
White LED |
| Accessories |
AC adapter, power cord, USB cable, Instruction manual, Image Mate CD-ROM, Infrared wireless remote control, AAA battery, Easy start-up guide, warranty sheet |
| Security slot |
Provided |
| Power source |
12V DC (AC adapter AC 100 - 240V) |
| Power consumption |
16.2 W (AC adapter included) |
| Dimensions (W x D x H) |
13.98" x 14.7" 16.79" (355 x 373.5 x 426.5 mm) setup
7.68" x 11.57" x 18.46" (195 x 294 x 469 mm) folded |
| Weight |
Approx. 7.1 lbs (3.2 kg) (main unit only) |
| Resolution |
1280x720 (50/60P)
1920x1080 (24/50/60P)
3840x2160 (24/25/30P) *1
4096x2160 (24P) *1
[720p][1080p] Progressive 60Hz supported
[720i][1080i] Interlaced not supported |
| Image Output Terminal |
HDMI 1.4 |
| Wireless Band Used |
5GHz: W52 (36,40,44,48ch)
2.4 GHz |
| Communication Range |
Approx. 98 feet (30 m)
(Depending on usage conditions) |
| Power Consumption |
5V / 1.5A |
| Compatible OS |
Windows® 8.1/10 (32-bit/64-bit) / Mac OS 10.11 / Android 4.4~ / iOS 10~ / All Chrome OS |
| External Dimensions (W X D X H) |
3.82 x 1.26 x 0.43 in. (97 x 32 x 11 mm)[HDMI connector not included] |
| Weight |
4.23 oz (120 g) |
| Operating Temperature |
0 to 40 Degrees Celsius |
