General Specifications |
Pressure |
Pressure valves |
2 valves |
Measuring range |
From -1 to 60 bar (-14 to 870 psi) |
Pressure sensing accuracy* |
±0.5% of full scale |
Available units |
psi, MPa, kPa, bar, Foot of head |
Resolution |
0.1 psi, 0.001 MPa, 1 kPa, 0.01 bar, 1 foot of head |
Overload |
65 bar (943 psi) |
Burst pressure |
150 bar (2175 psi) |
Operating temperature (handle) |
From -20 to 50°C (-4 to 122°F) |
Storage temperature (handle) |
From -20 to 60°C (-4 to 140°F) |
Temperature |
Number of probe |
2 clamp probes |
Temperature sensors |
High accuracy NTC thermistors |
Temperature sensor range** |
From -40 to 150°C (-40 to 302°F) |
Temperature accuracy* |
±1.3°C (±2.4°F)*** |
Maximum operating temperatures |
Jaws: 150°C (302°F) - Cable: 105°C (221°F) - Handle : 90°C (194°F) |
Available units |
°C, °F, K |
Resolution |
0.1°C, 0.1°F, 0.1 K |
Pipes diameter |
From 6 to 42 mm (0.2'' to 1.7'') |
Cable |
2 m (6 ft) length with strengthened Jack connector
3 points, Ø3.2 mm, in PVC, max. temperature 105°C (221°F) |
Operating temperature From |
-20 to 50°C (-4 to 122°F) |
Storage temperature From |
-20 to 60°C (-4 to 140°F) |
Device |
Environmental conditions of use |
Hygrometry: in non-condensing condition (< 80% RH)
Maximum altitude: 2000 m (6561')
Non-corrosive or combustible gases |
Battery life |
250 h (for one measurement every seconds @ 20°C / 68°F) |
Bluetooth® |
Class 1 Bluetooth® 4.2 |
Bluetooth® range |
Up to 30 m (98 ft) - Depending on smartphone and tablet Bluetooth® radio strength. |
Superheat and subcooling |
Automatically calculated by the Manifold app |
Refrigerant database |
126 refrigerant gases. Measurable products: CFC, HFC, HCFC, N, CO2, H20 (see the complete list on the user manual) |
Connections |
To installation: female ¼’’ FFL with Schrader® depressor
To flexible: male ¼’’ MFL with Schrader® valve |
Standards |
2011/65/EU RoHS II; 2012/19/EU WEEE; 2014/30/EU EMC; 2014/53/EU RED |
