Dwyer DPGWB-08 - Digital Pressure Gauge, 0-100 psi with 4-Digit Display

Name: Dwyer DPGWB-08 - Digital Pressure Gauge, 0-100 psi with 4-Digit Display
Brand: Dwyer
SKU: DwyerDPGWB-08
Price: 224.65 USD
Availability: InStock
Rating: 5.00 (1 reviews)

5 (1 Review) | Model: Dwyer DPGWB-08

Compare

Digital Pressure Gauge, 0-100 psi with 4-Digit Display

DPGWB-08 Digital Pressure Gauge
Push-button zero reduce installation and service time
High accuracy provides exceptional measurement for minimizing costly out of specification conditions
Selectable unit button provides reading in easily recognizable units

View Product Details

Your Price: $224.65

Sign-in for EDU Pricing!

In Stock:

Free shipping over $99 - Code: FREESHIP
Please note, FREE SHIPPING is only available on items that can ship via standard ground shipping and is only valid within the Contiguous United States. Any items that must ship via freight or to any destination outside of the Contiguous United States will be excluded. - USE CODE FREESHIP at checkout

Valid on Web Price Only!
View Payment Options

Request Quote

Recommended for you

Dwyer DPGWB-08

High accuracy provides an exceptional measurement for minimizing costly out-of-specification conditions
Push-button zero reduce installation and service time
Selectable unit button provides reading in easily recognizable units

Digital Pressure Gauge, 0-100 psi with 4-Digit Display

The SERIES DPGWB/DPGAB pressure gages offer 0.5% full-scale accuracy in a rugged, easy-to-use unit at prices comparable to mechanical gages. The DPGWB stainless steel wetted material makes it suitable for a wide variety of liquids or gases. The gages feature user-selectable units of a measure allowing one gage to be used for a variety of pressure scales. The DPGWB/DPGAB comes with a protective rubber boot to protect against short drops and rough handling.

Product Applications

Ideal for checking line pressures at system startup.
Process applications
Process start-up
OEM applications

Service	> DPGAB: Air and compatible gases; DPGWB: Liquids and compatible gases
Wetted Materials	> DPGAB: 316L SS, silicone sensor; DPGWB: Type 316L SS
Housing Materials	ABS plastic
Accuracy	±0.5% F.S. (includes linearity, hysteresis, repeatability)
Pressure Limits	2X pressure range. Vacuum range max. pressure is 30 psig.
Temperature Limits	30 to 120°F (-1 to 49°C)
Thermal Effect	0.05% FS/°F
Size	2.62" O.D. x 1.52" deep
Process Connections	1/4" male NPT
Display	4-digit LCD (.425" H x .234" W digits)
Power Requirements	9 V alkaline battery, included, user replaceable
Auto Shut-off	20 minute auto shut-off
Weight	5.6 oz (160 g)

Tech Specs

Process / Calibration/Pressure Calibration/Process Pressure Gauges Template
Type (Pressure)	Gauge, Vacuum
Style (Press Gauge)	Digital Indicating
Accuracy (Digital-ASME B40.100 / B40.7 Grades)	0.5% F.S. (Grade 2A) Process / Industrial
Units of Measure (Gauges)	bar, cmH2O, ftH2O, inH2O, inHg, kg/cm2, kPa, mbar, mmHg, psi Units of Measure (Gauges) oz/in²
Gauge Case Material	ABS
Special Functions / Options (Press Gauge)	NACE Certified (sour gas), Protective Rubber Boot, Zero Function
Power (Press Gauges)	Battery
Connection Location (Press Gauges)	Lower
Maximum Range Pressure (Gauges)	100 psi
Minimum Range Pressure (Gauges)	0 psi
# Digit Display	4
Process Connection	NPT (National Pipe Thread)
Test Equipment General Attributes
Unique Features	• Range 0-100 psi with 4-digit display • ±0.5% accuracy, battery powered
Warranty	1 YEARS
Warranty Details	The Seller warrants all Dwyer Instruments and equipment to be free from defects in workmanship or material under normal use and service for a period of one year from date of shipment. Liability under this warranty is limited to repair or replacement EXW Ex Works Dwyer Instruments, Inc. of any parts which prove to be defective within that time or repayment of the purchase price at the Seller's option provided the instruments have been returned, transportation prepaid, within one year from date of purchase. All technical advice, recommendations and services are based on technical data and information which the Seller believes to be reliable and are intended for use by persons having skill and knowledge of the business, at their own discretion. In no case is Seller liable beyond replacement of equipment EXW Ex Works Dwyer Instruments, Inc. or the full purchase price. This warranty does not apply if the maximum ratings label is removed or if the instrument or equipment is abused/altered.
Safety Approval	CE
Product Weight	0.35 LBS
Shipping Weight	0.50 LBS
Battery Type	9v
Power Supply Voltage	Battery Powered
Country of Origin	United States
Other Information	Size: : 2.62˝ O.D. x 1.52˝ deep
