Dwyer DPG-108 - Digital Pressure Gauge (0.25 Accuracy, 0-500 psi)

Name: Dwyer DPG-108 - Digital Pressure Gauge (0.25 Accuracy, 0-500 psi)
Brand: Dwyer
SKU: DwyerDPG-108
Price: 292.00 USD
Availability: InStock

0 reviews | Model: Dwyer DPG-108

Compare

Digital Pressure Gauge (0.25 Accuracy, 0-500 psi)

Selectable engineering units: 500.0 psi, 35.15 kg/cm², 34.48 bar, 1018" Hg, 1154 ft w.c., 3448 kPa, 8000 oz/in², CE and FM approved.
High accuracy provides exceptional measurement minimizing costly out of specification conditions
Backlit 4-digit display provides clear parallax-free reading reducing potential for errors
Battery-powered gage with auto-shutoff eliminates wiring and prolongs battery life reducing service calls
Push-button zero reduce installation and service time

View Product Details

Your Price: $292.00

Sign-in for EDU Pricing!

In Stock:

Free shipping over $99 - Code: FREESHIP
Please note, FREE SHIPPING is only available on items that can ship via standard ground shipping and is only valid within the Contiguous United States. Any items that must ship via freight or to any destination outside of the Contiguous United States will be excluded. - USE CODE FREESHIP at checkout

Valid on Web Price Only!
View Payment Options

Request Quote

Items in This Series


Product	Dwyer DPG-108 Digital Pressure Gauge (0.25 Accuracy, 0-500 psi)	Dwyer DPG-103 Digital Pressure Gauge (0.25 Accuracy, 0-30 psi)	Dwyer DPG-105 Digital Pressure Gauge (0.25 Accuracy, 0-100 psi)	Dwyer DPG-106 Digital Pressure Gauge (0.25 Accuracy, 0-200 psi)	Dwyer DPG-107 Digital Pressure Gauge (0.25 Accuracy, 0-300 psi)
Price
In Stock
Type (Pressure)	Gauge	Gauge, Vacuum	Gauge	Gauge	Gauge
Style (Press Gauge)	Digital Indicating	Digital Indicating	Digital Indicating	Digital Indicating	Digital Indicating
Units of Measure (Gauges)	bar, ftH2O, inHg, kg/cm2, kPa, psi	bar, cmH2O, ftH2O, inH2O, inHg, kg/cm2, kPa, mbar, mmHg, psi	bar, cmH2O, ftH2O, inH2O, inHg, kg/cm2, kPa, mbar, mmHg, psi	bar, ftH2O, inH2O, inHg, kg/cm2, kPa, psi	bar, ftH2O, inH2O, inHg, kg/cm2, kPa, psi
Compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare

Recommended for you

Dwyer DPG-108 Accessories

Choose a Category

General Accessories

for the Dwyer DPG-108

Dwyer A-183 Dwyer Protective Rubber Boot, A-183, For Dwyer DPG Models (gage not included)

Catalog: A-183

(1)

In Stock!

Add to Cart

Dwyer DPG-108

Accuracy: 0.25
0-500 psi
Backlit 4-digit display
Replacement for legacy analog gauges

Digital Pressure Gauge (0.25 Accuracy, 0-500 psi)

Replace your outdated analog gages with the new SERIES DPG Digital Pressure Gauge. The Series DPG has a high ±0.25% or ±0.5% full-scale accuracy. The 4 digits digital display will reduce the potential for errors in readings by eliminating parallax errors commonly produced with analog gages. Series DPG is battery-powered and has an auto-shutoff to conserve battery life. Battery life, on average, will last 2000 hours. A 4 button keypad allows easy access to features without the need to work through complex menus or difficult key combinations. These features include backlight, peak and valley, tare or auto-zero, and conversion of the pressure units.

General Specifications
Service:	Compatible liquids and combustible gases (for FM listing see Agency Approvals below).
Wetted Materials:	Type 316L SS.
Housing Materials:	Polycarbonate front and back cover, anodized aluminum extruded housing with recessed grooves, polycarbonate overlay, Buna-N O-rings, 316L SS sensor construction.
Accuracy:	DPG-000: 0.5% FS; DPG-100: ±0.25% FS; ±1 least significant digit @ 70°F (21°C) (includes linearity, hysteresis, repeatability).
Pressure Limit:	2x pressure range for models ≤1000 psi; 5000 psi for 3000 psi range; 7500 psi for 5000 psi range.
Enclosure Rating:	Designed to meet NEMA 4/4X (IP66).
Temperature Limits:	0 to 130°F (-18 to 55°C).
Thermal Effect:	Between 70 to 130°F is 0.016%/F. Between 32 to 70°F is 0.026%/F. Between 10 to 32°F is 0.09%/F. Between 0 to 10°F is 0.50%/F.
Size:	3.00" OD x 1.90" deep (max).
Process Connection:	1/4" male NPT.
Weight:	8.84 oz (275 g).
Display:	4 digit (.425" H x .234" W digits).
Power Requirements:	(2) AAA alkaline batteries, included, user replaceable.
Battery Life:	2000 hours typical; Low battery indicator.
Auto Shut-Off:	Gage: 60 minute auto shut-off. Auto shut-off may be disengaged. Backlight: 2 minute auto shut-off.
Agency Approvals:	DPG-000: CE; DPG-100: CE, FM approved to be intrinsically safe for Class I, Division 1, Groups A, B, C and D, for ranges 0-15 and 0-3000 psi.

Process / Calibration/Pressure Calibration/Process Pressure Gauges Template
Type (Pressure)	Gauge
Style (Press Gauge)	Digital Indicating
Units of Measure (Gauges)	bar, ftH2O, inHg, kg/cm2, kPa, psi Units of Measure (Gauges) oz/in2
Gauge Case Material	Aluminum
Special Functions / Options (Press Gauge)	Panel Mounting, Zero Function
Power (Press Gauges)	Battery
Connection Location (Press Gauges)	Lower
Maximum Range Pressure (Gauges)	500 psi
Minimum Range Pressure (Gauges)	0 psi
# Digit Display	4
Process Connection	NPT (National Pipe Thread)
Test Equipment General Attributes
Unique Features	Selectable engineering units: 500.0 psi, 35.15 kg/cm², 34.48 bar, 1018" Hg, 1154 ft w.c., 3448 kPa, 8000 oz/in², CE and FM approved
Warranty	1 YEARS
Warranty Details	The Seller warrants all Dwyer Instruments and equipment to be free from defects in workmanship or material under normal use and service for a period of one year from date of shipment. Liability under this warranty is limited to repair or replacement EXW Ex Works Dwyer Instruments, Inc. of any parts which prove to be defective within that time or repayment of the purchase price at the Seller's option provided the instruments have been returned, transportation prepaid, within one year from date of purchase. All technical advice, recommendations and services are based on technical data and information which the Seller believes to be reliable and are intended for use by persons having skill and knowledge of the business at their own discretion. In no case is Seller liable beyond replacement of equipment EXW Ex Works Dwyer Instruments, Inc. or the full purchase price. This warranty does not apply if the maximum rating label is removed or if the instrument or equipment is abused, altered,
Safety Approval	CE, FM
IP Rating	IP66 IP Rating Enclosure: IP66
Product Weight	0.6 LBS
Shipping Weight	0.75 LBS
Data Logging	No
Calibration Included	None
Battery Type	AAA
Power Supply Voltage	Battery Powered
Country of Origin	United States
Other Information	Dimensions: : 3.00" OD x 1.90" deep (max)
