| General Specifications |
| Display |
Size: 110 mm (4.3in) diagonal. 480 x 272 pixels. LCD colour display with touch screen |
| Internal memory |
8Gb (nominal) user memory for automated procedures, calibration data and data log files |
| Languages |
English (default), Chinese, Dutch, French, German, Italian, Japanese, Korean, Portuguese, Russian, Spanish |
| Pressure units |
25 pressure units are available for the user to select (country restrictions may apply) Calibration certificates are provided with data in three pressure units based on bar, psi (or inH2O or inHg depending on range) and Pa |
| Operating temperature |
-10° to 50 °C (14° to 122 °F). 0° to 40 °C (32° to 104 °F) when powered from optional mains adaptor IO620-PSU. For DPI 612 hFlexPro +4 to +50°C (39 to 122°F) with water as media |
| Storage temperature |
-20° to 70 °C (-4° to 158 °F). For DPI 612 hFlexPro +4 to +70°C (39 to 158°F) with water as media |
| Ingress protection |
IP 54. Protected against dust and splashing water from any direction |
| Humidity |
0 to 90% RH none condensing. To Def Stan 66-31, 8.6 cat III |
| Shock / vibration |
BS EN 61010-1:2010 / MIL-PRF-28800F CLASS 2. 1 m drop tested |
| Altitude |
Up to 2000m |
| EMC |
BS EN 61326-1:2013 |
| Electrical safety |
BS EN 61010-1:2010 |
| Pressure safety |
Pressure Equipment Directive - Class: Sound Engineering Practice (SEP) |
| Enclosure materials |
Polycarbonate, polyamide, polypropylene, acrylic, cotton |
| Approved |
CE marked |
| Power supply |
Lithium-ion battery GE Part number: CC3800GE supplied as standard; Capacity: 3800 mAh 14.1Wh. Nominal voltage: 3.7 V. Charge temperature: 0° to 40°C (32° to 104°F) Discharge temperature: -10° to 60°C (14° to 140°F). Charge/discharge cycles: > 500 > 70% capacity. Battery eliminator / charger (GE part number: IO620-PSU) supplied as standard. Alternatively 8 AA alkaline cells (not supplied) |
| Battery life |
For lithium-ion battery 12 to 26 hours depending on functions
For AA alkaline cells 18 to 26 hours depending on functions |
| Connectivity |
USB type A, USB type mini B |
