Dranetz DranEST III+H Automated Electrical Safety Tester

Name: Dranetz DranEST III+H Automated Electrical Safety Tester
Brand: Dranetz
SKU: DranetzM7010-V023
Price: 3141.00 USD
Availability: InStock

0 reviews | Model: Dranetz M7010-V023

Compare

DranEst III + H - High voltage up to 6KV DC; Test Current +/-200mA DC or 25A AC; Memory for 125 Tests; Test Procedures IEC 61010; 60355; 60950

Test Current +/-200mA DC or 10A AC
High Voltage up to 4 kV DC
Memory for 125 Tests
Test Procedures IEC 61010, 60335, 60950, IEC 62353
Adapter Set for International Sockets

Tests:

Ground Bond Testing
Protective Conductor Resistance
Insulation ResistanceTests
Leakage Current Tests
High Voltage Tests
Function Tests, including power

Operating Modes:

Manual
Auto-Sequence
Function Testing

View Product Details

List Price: $3,490.00

In Stock:

View Payment Options

Recommended for you

DranEST III +H

Applications

DranEST III+ Electrical Safety Analyzer tests Laboratory and Hospital Equipment to both North American and International Standards. Also T & M, Electrical Appliances and IT Equipment are tested to IEC Standards.

Features

The DranEST III+ has unique capabilities for testing the electrical safety of:

Electrical Medical Devices according to IEC 60601, UL 60601, UL 544, UL 187, and NFPA 99
Recurring Testing of ME Equipment according to IEC 62353
Electrical Measuring, Control and Laboratory Devices according to IEC 61010 & UL 61010)
Safety of Household Appliances according to IEC 60335
Data Processing Equipment according to IEC 60950 and UL 1950
High Voltage Testing as per IEC 60950, IEC 61010, IEC 60335 and IEC 60601

Electrical Safety
Safety Class	I per IEC 61010-1/EN 61010-1/VDE 0411-1
Nominal Voltage	115/230 V
Test Voltage	3.7 kV, 50 Hz
Measuring	250 V CAT II
Category
Contamination	Level 2
Safety Shutdown	for residual current at device under test > 25 mA, disconnecting time < 100 ms probe current > 10 mA, < 1 ms
Electromagnetic Compatibility EMC
Product Standard	DIN EN 61326:2002
Mechanical Design
Display	multiple dot matrix display, 128 x 128 pixels
Dimensions	test instruments without high-voltage module LxWxH: 292 mm x 138 mm x 243 mm test instruments with high-voltage module: LxWxH: 292 mm x 138 mm x 300 mm
Weight	instrument: approx. 4.5 kg instrument w/ HV test: approx. 5.24 kg instrument w/ 25 A PE test: approx. 5.5 kg instr. w/ 25 A PE & HV test: approx. 5.9 kg
Protection housing	IP 40
Terminals	IP 20 per DIN VDE 0470, part 1/EN 60529
Ambient Conditions
Storage Temperature	- 20°C ... + 60°C
Operating Temperature	- 10°C ... + 50°C
Accuracy Range	0°C ... + 50°C
Relative Humidity	max. 75%, no condensation
Elevation	max. 2000 m
Deployment	indoors, outdoors: only under specified ambient conditions
RS 232 Data Interface
Type	RS 232C, serial, per DIN 19241
Format	9600, N, 8, 1
Connector	9-pin subminiature socket connector
Power Supply
Line Voltage	103.5 V - 126.5 V or 207 V - 253 V
Line Frequency	50 Hz or 60 Hz
Power Consumption	approx. 30 VA for 10 A test current approx. 95 VA, test duration max. 70 s
Warranty	2 years for workmanship.
Calibration	The DranEST IIII+ comes with a Factory Calibration DKD Certificate recognized by NIST, ANSI, ISO 9001 certified

Interference Emission		Class
EN 55022		B
Interference Immunity	Test value	Feature
EN 61000-4-2	Contact/atmosphe. – 4 kV/8 kV	A
EN 61000-4-3	10 V/M	C
EN 61000-4-4	Mains connection - 2 kV	B
EN 61000-4-5	Mains connection - 1 kV	A
EN 61000-4-6	Mains connection - 3 V	A
EN 61000-4-11	0.5 period / 100%	A

Tech Specs

Safety Testing / Surge Testing/Hipot Tester Template
Test Type Hipot	DC, Ground Bond, IR
Max DC Test Voltage	6 kV
Min DC Test Voltage	1 V
Max Trip Current AC Test	10 A (10000 mA)
Max Trip Current DC Test	200 mA
Programmable (hipot)	Yes
Insulation Resistance Test	Yes
IR Test Voltage	1,000 V, 100 V, 2,000 V, 5,000 V
Connection Type	Probe
Arc Detection	No
Scanning control capable for Multipoint Testing	No
Test Equipment General Attributes
Unique Features	Test Current +/-200mA DC or 10A AC, High Voltage up to 6 kV DC, Memory for125 Tests, Test Procedures IEC 61010, 60335, 60950, IEC 62353, Adapter Set for International Sockets
Warranty	2 YEARS
Safety Approval	CSA
Interfaces I/O	RS-232
IP Rating	IP40
Product Weight	12 LBS
Data Logging	Yes
ECCN Number	3B992
Calibration Included	Factory Calibration
Power Supply Voltage	120V/220V Universal
Country of Origin	Germany
Other Information	Safety Class: I per IEC 61010-1/EN 61010-1/VDE 0411-1 Nominal Voltage: 115/230 V Test Voltage: 3.7 kV, 50 Hz Measuring: 250 V CAT II Contamination: Level 2 Safety Shutdown: for residual current at device under test 25 mA, disconnecting time 100 ms probe current 10 mA, 1 ms Product Standard: DIN EN 61326:2002 Display: multiple dot matrix display, 128 x 128 pixels Dimensions: test instruments without high-voltage module LxWxH: 292 mm x 138 mm x 243 mm test instruments with high-voltage module: LxWxH: 292 mm x 138 mm x 300 mm Weight: instrument: approx. 4.5 kg instrument w/ HV test: approx. 5.24 kg instrument w/ 25 A PE test: approx. 5.5 kg instr. w/ 25 A PE & HV test: approx. 5.9 kg Protection housing: IP 40 Terminals: IP 20 per DIN VDE 0470, part 1/EN 60529 Storage Temperature: - 20?C ... + 60?C Operating Temperature: - 10?C ... + 50?C Accuracy Range: 0?C ... + 50?C Relative Humidity: max. 75%, no condensation Elevation: max. 2000 m Deployment: indoors, outdoors: only under specified ambient conditions Type: RS 232C, serial, per DIN 19241 Format: 9600, N, 8, 1 Connector: 9-pin subminiature socket connector Line Voltage: 103.5 V - 126.5 V or 207 V - 253 V Line Frequency: 50 Hz or 60 Hz Power Consumption: approx. 30 VA for 10 A test current approx. 95 VA, test duration max. 70 s Warranty: 2 years for workmanship. Calibration: The DranEST IIII+ comes with a Factory Calibration DKD Certificate recognized by NIST, ANSI, ISO 9001 certified
