| DranTech PRO - TRMS Digital Multimeter These multimeters are suitable for universal use in electrical engineering, electrical installation, laboratory applications, telecommunication, technical training, as well as for troubleshooting in the field. Three Connector Terminals with patented Automatic Blocking Sockets* All current ranges are implemented via a single connector socket which prevents any possibility of operator error. Beyond this, the automatic blocking sockets prevent incorrect connection of the measurement cables, as well as selection of the wrong measured quantity. Danger to the user, the instrument and the device under test resulting from operator error is therefore eliminated. * Patented (patent no. DE 40 27 801 C2 and US 5,166,599) Overload Protection The instrument is safeguarded for up to 1000 V in all measuring functions by overload protection. Voltages of greater than 1000 V and current of greater than 10 or 16 A are indicated acoustically. RMS Value with Distorted Waveforms The measuring method applied allows for waveform independent RMS measurement (TRMS AC and AC+DC) for voltage and current up to 10 kHz). Selectable Filter for V AC Measurement A 1 kHz low-pass filter can be activated if required, for example when measuring motor voltage at electronic frequency converters. Battery Capacity Indication - Power Saving Circuit The battery load capacity is indicated on the display. If user selected, the device is switched off automatically if the measured value remains unchanged for a period of between 10 and 59 minutes (adjustable), and if none of the controls are activated during this time. DKD Calibration Certificate Multimeters are furnished with an internationally accepted DKD calibration certificate (recognized by EA and ILAC). After the specified calibration interval has elapsed (recommended interval: 1 to 3 years), the multimeters can be inexpensively recalibrated by any calibration laboratory. Scope of Delivery - Multimeter with 1 pair of safety test leads (1.5 m) with 4 mm diameter, 1000 V CAT III, 600 V CAT IV (KS17-2)
- 2 alkaline batteries, 1.5 V, type AA
- CD with operating instructions,
- DKD calibration certificate
- Pack of 10 superfast Fuses 10A/1kV
- HC20 Hardcase
|
