Dranetz M240J DranTech XTRA TRMS Digital Multimeter

Name: Dranetz M240J DranTech XTRA TRMS Digital Multimeter
Brand: Dranetz
SKU: DranetzM240J
Price: 405.00 USD
Availability: InStock

0 reviews | Model: Dranetz M240J

Compare

DranTech Xtra Meter Only (DranTech Xtra; Voltage leads)

Voltage 1000 V and current 10 A (Rms or DC) max measurements
Frequency, RMS value of AC measuring voltage
4½-place display (11,999 counts), with display illumination
Automatic Blocking Sockets to prevent incorrect connection of the measurement cables
1 khz low pass filter for V AC measurements
Square Wave signal measurement with amplitudes of 2 to 5 V and frequencies from 100 Hz to 1 Mhz
Capacitance measurement to 1000 uF
Resistance measurement to 40 Meg ohms
Temperature measurement in degrees Fahrenheit or Celsuis
Thermocouple measurement capabilibities of Type J and K thermocouples
Battery run time, approximately 200 hrs on 2 AA alkalines
Overload Protection, audible sound is employed if upper voltage or current range is exceeded
Fuse indicator displays message that the fuse for current measurements needs to be replaced
Bandwidth - 100 kHz
Frequency - 1 Mhz
Memory for data logging - 540 kb
Remote configured, and momentary and stored measurement data via the bidirectional infrared interface with DranWin software

View Product Details

List Price: $450.00

In Stock:

View Payment Options

Recommended for you

Accessories

Choose a Category

DMM Probe Kits

for the Dranetz M240J

Cal Test CT4038 DMM Accessory Kit - Get the most out of your meter with advanced test...

Catalog: CT4038

(13)

In Stock!

Add to Cart

Cal Test CT4039 DMM Accessory Kit - Set pf Leads, removable tips, and deluxe alligator...

Catalog: CT4039

(4)

In Stock!

Add to Cart

DranTech Xtra Meter Only (DranTech Xtra, leads)

DranTech XTRA - TRMS Digital Multimeter

These multimeters are suitable for universal use in electrical engineering, electrical installation, laboratory applications, telecommunication, technical training, as well as for troubleshooting in the field.

Remote configured, and momentary and stored measurement data via the bidirectional infrared Interface with DranWin software

Three Connector Terminals with patented Automatic Blocking Sockets*

All current ranges are implemented via a single connector socket which prevents any possibility of operator error. Beyond this, the automatic blocking sockets prevent incorrect connection of the measurement cables, as well as selection of the wrong measured quantity. Danger to the user, the instrument and the device under test resulting from operator error is therefore eliminated. * Patented (patent no. DE 40 27 801 C2 and US 5,166,599)

Overload Protection

The instrument is safeguarded for up to 1000 V in all measuring functions by overload protection. Voltages of greater than 1000 V and current of greater than 10 or 16 A are indicated acoustically.

RMS Value with Distorted Waveforms

The measuring method applied allows for waveform independent RMS measurement (TRMS AC and AC+DC) for voltage and current up to 10 kHz).

Selectable Filter for V AC Measurement

A 1 kHz low-pass filter can be activated if required, for example when measuring motor voltage at electronic frequency converters.

Battery Capacity Indication - Power Saving Circuit

The battery load capacity is indicated on the display. If user selected, the device is switched off automatically if the measured value remains unchanged for a period of between 10 and 59 minutes (adjustable), and if none of the controls are activated during this time.

DKD Calibration Certificate

Multimeters are furnished with an internationally accepted DKD calibration certificate (recognized by EA and ILAC). After the specified calibration interval has elapsed (recommended interval: 1 to 3 years), the multimeters can be inexpensively recalibrated by any calibration laboratory.

Scope of Delivery

Multimeter with 1 pair of safety test leads (1.5 m) with 4 mm diameter, 1000 V CAT III, 600 V CAT IV (KS17-2)
2 alkaline batteries, 1.5 V, type AA
CD with operating instructions,
DKD calibration certificate
Pack of 10 superfast Fuses 10A/1kV
HC20 Hardcase

Applicable Regulations and Standards
IEC 61010, Part 1	2001:Safety requirements for electrical equipment for measurement, control and laboratory use
IEC 61326	Electrical equipment for control technology and laboratory use - EMC requirements
IEC 60529	Test instruments and test procedures - degrees of protection provided by enclosures (IP code)
Internal Clock	Time format DD.MM.YYYY hh:mm:ss Resolution 0.1 s Accuracy ±1 min. per month Temperature Influence 50 ppm/K
Power Supply
Battery	2 ea. 1.5 V, size AA, alkaline manganese per IEC LR6 (2 ea. 1.2 V NiMH rechargeable battery possible)
Service life with alkaline manganese	approx. 200 hours
Battery test	Battery capacity display with battery symbol in 4 segments: Display of momentary battery voltage via menu function. Power OFF function: Multimeter is switched off automatically: - If battery voltage drops to below approx. 1.8 V If none of the keys or the rotary switch are activated for an adjustable duration of 10 to 59 minutes, and the multimeter is not in continuous operating mode
Fuse	Fuse FF (UR) 10 A/1000 V AC/DC; 10 mm x 38 mm,
Switching capacity	30 kA at 1000 V AC/ DC, protects the current measurement input in the 100 µA through 10 A ranges
Display
LCD panel	(65 mm x 36 mm) with analog and digital display including unit of measure, type of current and various special functions
Background	Illumination is switched off approximately 1 minute after it has been activated (backlit display)
Analog
Display	LCD scale with bar graph or pointer, depending on the selected parameter
setting
Scaling	With 4 division lines each, 1 bar/pointer corresponds to 500 digits at the digital display
Polarity display	In auto-ranging mode
Overflow display	With the symbol Δ
Update rate	40 measurements per second and display refresh
Digital
Display/char. height	7-segment characters / 15 mm
Resolution	4¾ digits, 60,000 counts
Overflow display	"OL" is displayed for ≥=60,000
Polarity display	"-" (minus sign) is displayed if pos. lead is connected to "-"
Measuring rate	10 and 40 measurements per second with the Min-Max function except for the capacitance, frequency and duty cycle measuring functions
Refresh rate	2 times per sec., every 500 ms
Acoustic Signals
For voltage	Intermittent signal at above 1000 V
For current	Intermittent signal at above 10 A Continuous signal at above 16 A
Electrical Safety	Per IEC 61010-1:2001 Cat. III 1000 V - Cat. IV 600 V Test voltage 6.7 kV~
Ambient Conditions (to meet all specs)
Accuracy range	0°C ... +40°C
Operating temp. range	-10°C ... +50°C
Storage temp. range	-25°C ... +70°C (w/o batteries)
Relative humidity	Max.95%, no condensation allowed
Elevation	To 2000 m
Deployment	Indoors, except within specified ambient conditions
Electromagnetic Compatibility EMC
Interference emission	IEC 61326: May 2004, class B
Interference immunity	IEC 61326: May 2004, appendix E IEC 61000-4-2: Dec. 2001 Feature B - 8 kV atmospheric discharge 4 kV contact discharge IEC 61000-4-3: Dec. 2001 Feature A - 3 V/m
Mechanical Design
Housing	Impact resistant plastic (ABS)
Dimensions	200 x 87 x 45 mm (without protective rubber holster)
Weight	Approx. 0.35 kg with batteries
Protection Housing	IP 52
Data Interface
Type	Optical via infrared light through the housing
Data transmission	Serial, bidirectional (not IrDa compatible)
Protocol	Device specific
Baud rate	38,400 baud
Functions	- Select/query measuring functions and parameters -Query momentary measurement data ---Read out stored measurement data The USB plug-in interface adapter (see accessories) is used for adaptation to the PC?s USB port.
Internal Measured Value Storage	Memory capacity 4 MBit / 540 kB for approx. 15,400 measured values with date and time stamp
Warranty	24 months for materials and workmanship 1 to 3 years for calibration (depending upon application)

Tech Specs

Multimeters Template
Style	Hand-Held
Measures AC V	Yes
Measures DC V	Yes
Measures AC A	Yes
Measures DC A	Yes
True RMS	Yes
Maximum Voltage AC	1000 V
Resolution AC Volts	10 uV (0.01 mV)
Maximum Voltage DC	1000 V
Resolution DC Volts	10 uV (0.01 mV)
Maximum Current AC	10 A
Minimum Current AC	10 nA (0.00001 mA)
Resolution AC Current	10 nA (0.00001 mA)
Maximum Current DC	10 A
Minimum Current DC	10 nA (0.00001 mA)
Resolution DC Current	10 nA (0.00001 mA)
Basic Accuracy V DC	0.09%
# Digit Display	4.75
Counts	60000 .
Backlight	Yes
Manual/Autoranging	Both
Decibels	No
Resistance	Yes
Frequency	Yes
Capacitance	Yes
Temperature	Yes
Diode Testing	Yes
CAT Rating	IV
Intrinsically Safe	No
Peak Hold	Yes
Overload Protector	Yes
Kelvin 4-Wire Measurement Capability	No
Wireless Display	No
Data Hold	Yes
Low-Pass Filter	Yes
Test Equipment General Attributes
Unique Features	This digital multimeter is suitable for universal use in electrical engineering, electrical installation, laboratory applications, telecommunication, technical training, as well as for troubleshooting in the field.
Warranty	24 MONTHS (2 YEARS)
Safety Approval	CSA
Interfaces I/O	IR
Product Weight	1 LBS
Product Height	45 IN
Product Length	200 IN
Product Width	87 IN
Data Logging	Yes
ECCN Number	3B992
Calibration Included	Factory Calibration
Power Supply Voltage	Battery Powered
Country of Origin	Germany
