Compliance HT-10kVac-100mA Hipot Tester, 0-10kVac 100mA

Name: Compliance HT-10kVac-100mA Hipot Tester, 0-10kVac 100mA
Brand: Compliance West
SKU: ComplianceHT-10kVac-100mA
Availability: InStock

0 reviews | Catalog: HT-10kVac-100mA | Model: Compliance West HT-10kVac-100mA

Compare

Hipot Tester, 0-10kVac 100mA

Cannot Ship Air

Output: 0-10kVac
Meter Accuracy: Voltage ±3% 500-10000V; Current ±4% 5mA-100mA
Test Time: Defeatable, 1-60 sec
Ramp Time: Manual only

View Product Details

In Stock:

View Payment Options

Recommended for you

Compliance HT-10kVac-100mA Hipot Tester, 0-10kVac 100mA

The HT10kVac has AC output to 10kV with current capability to 100mA continuous duty. Leakage current limits can be set with the rear panel knob from 0.5mA to 100mA. Normal operation stops testing when a leakage current greater than the set amount or when a dielectric breakdown is encountered. Also, if desired, testing can be set to continue to examine problem areas.

Safety Testing / Surge Testing/Hipot Tester Template
Test Type Hipot	AC
Max AC Test Voltage	10000 V (10 kV)
Min AC Test Voltage	0 V
Max Trip Current AC Test	100 mA
Min Trip Current AC Test	5 mA
Programmable (hipot)	No
Ground Continuity Current AC	47 mA (0.047 A)
Insulation Resistance Test	No
Connection Type	Nema Socket
Arc Detection	Yes
Scanning control capable for Multipoint Testing	No
Test Equipment General Attributes
Warranty	1 YEARS
Product Weight	300 LBS
Calibration Included	NIST Calibration
Power Supply Voltage	120V 50/60 Hz
