Compliance West DF80 DSW AAMI DF-80 App DD Damped Sinusoidal Waveform

Name: Compliance West DF80 DSW AAMI DF-80 App DD Damped Sinusoidal Waveform
Brand: Compliance West
SKU: ComplianceDF80 DSW
Price: 4573.05 USD
Availability: InStock

0 reviews | Catalog: DF80 P DSW | Model: Compliance West DF80 DSW

Compare

AAMI DF-80 App DD Damped Sinusoidal Waveform

Generates the waveform required by AAMI DF 80 App. DD, Specifications for damped sinusoidal output waveforms.
Designed with operator safety in mind: Set up the EUT to the right and behind the tester, and a right-handed operator will find himself standing to the left of the tester, allowing maximum separation.
Theoretical graphs and actual graphs showing the output of your tester are included with each MegaPulse Defib Surge, allowing easy sanity checks and proof to visiting agency engineers of test setups.
360J output; 50 ohms impedance standard.
Reverse polarity waveforms available by pushing a button on the front panel. No need to change the test setup. Positive polarity indication minimizes errors.
Front panel voltage meter shows residual voltage in charging circuit for safer operation.
1-year calibration cycle.
All test leads included.
1 year warranty

View Product Details

List Price: $4,695.00

In Stock:

View Payment Options

Recommended for you

MegaPulse Surge Tester

360J Output; 50 ohms Impedance Standard

Theoretical graphs and actual graphs showing the output of your tester are included with each MegaPulse Defib Surge, allowing easy sanity checks and proof to visiting agency engineers of test setups.

Compliance West DF80 DSW AAMI DF-80 App DD Damped Sinusoidal Waveform

The MegaPulse DF-80 DSW Surge Tester is designed to conduct the test shown in AAMI DF80, App. DD, Table US.DD.1 and Figure US.DD.1 - Damped sinusoidal waveform parameters. The resulting waveform is in accordance with those requirements.

The DF-80P DSW is built with 50 ohms output impedance. If another impedance is desired, please contact us.

The DF-80P DSW is designed as a laboratory instrument with a duty cycle 1 pulse every 5 minutes continuous within tolerances. Other duty cycles are optionally available:
Option 60. Allows one test every 60 sec continuously.
Option 12. Allows one test every 12 sec continuously.

The power output of the DF-80P DSW is 360J. A front panel switch reverses the output polarity. Joules consumed can be read directly from the front panel after every pulse.

Positive and negative pulses can be delivered manually using the front panel buttons, or the pulses can be set to operate under computer control using the TestMinder Megapulse PF option.

MegaPulse DF-80P DSW ships with cables, graphs of theoretical and actual waveforms, and a Calibration Certificate. One-year warranty.

Controls, Indicators, Connectors – MegaPulse DF-80P Front Panel

ITEM	NAME	FUNCTION
1	VOLTAGE Adjust Knob	Adjust the voltage set point in the tester. Turn Clockwise to increase the output voltage after the CHARGE button has been pressed. Turn the knob fully counterclockwise (lowest voltage setting) before the start of each test, and afterthe end of each test.
2	POLARITY switch	Toggles the output pulse polarity from Normal to Reverse, Normal for positive and Reverse for Negative, The pulse will appear on the Output jack relative to the return jack The polarity switch only operates when the CHARGE indicator is lit and the voltage on the display meter is less than 180V. The polarity is Normal when the NOR indicator is lit and, Reverse when the REV indicator is lid.
3	NOR REV indicator	Indicates the state of the Output Polarity switch. NOR indicates Normal (Positive) position. REV indicates Reverse (Negative) position.
4	CHARGE switch	Starts the charge process of the tester capacitor. The CHARGE indicator will turn off after the CHARGE switch is pressed, and the TRIGGER indicator will turn on. The charge process will stop after 2 minutes if the TRIGGER button is not pressed.
5	CHARGE indicator	This Yellow indicator is lit to show that pressing the CHARGE switch is the next logical step in a test sequence. CHARGE indicator is lit when the tester is turn ON an after pressing TRIGGER button. CHARGE indicator will go out after pressing CHARGE button. CHARGE and TRIGGER Indicators will be blinking if the Interlock Switch is open. (Only testers with Interlock SwitchOption)
6	TRIGGER switch	Triggers the output impulse waveform. The impulse waveform will appear across the output leads.
7	TRIGGER indicator	This Red indicator is lit to show that the tester can be trigger. TRIGGER indicator is lit for 2 minutes after the CHARGE button is pressed. TRIGGER indicator will go out after pressing TRIGGER button. TRIGGER and CHARGE Indicators will be blinking if the Interlock Switch is open (Only testers with Interlock Switch Option) TRIGGER indicator will blink at when the Voltage. This effect will remain on until the TRIGGER switch is pressed. (Only testers with PC Interface option)
8	VOLTAGE meter	Displays the output voltage set point. The voltage reading will increase from zero to the voltage set point when the CHARGE button is pressed. Note that the Voltage meter may indicate that some residual voltage is present on the main storage capacitor, even when the tester is first turned ON. This is due to inherent charging of the internal capacitors. Pressing the TRIGGER switch will discharge the capacitors. Note that the peak amplitude of the measured output waveform is proportional to the voltage that is read of the front panel of the MegaPulse, but it will always be somewhat lower. This is because the meter on the MegaPulse is measuring the voltage on the main impulse storage capacitor. This voltage will intentionally dissipate to some extent before reaching the output leads. The meter will start to flash at 12210V to indicate that voltage is in the maximum limits. If unit includes PC Interface and the Keyboard is locked, the display will show OFF when a button is pressed.
9	OUTPUT jack	The impulse waveform appears on the OUTPUT jack, referenced to the RETURN jack. When the POLARITY switch is in the Normal position (NOR indicator is lit) the output will be a positive pulse. When the POLARITY switch is in the Reverse position (REV indicator is lit) the output will be a negative pulse.
10	RETURN jack	This is the return for the impulse waveform. This jack is referenced to the chassis of the MegaPulse, and is referenced to earth ground as long as the MegaPulse is properly grounded. Even though this jack is referenced to ground, it should be treated as hazardous whenever the MegaPulse is turned ON.

Controls, Indicators, Connectors – MegaPulse DF-80P Rear Panel

ITEM	NAME	FUNCTION
1	Appliance Inlet /Fuseholder / Power Switch	Use supplied cordset to connect the MegaPulse DF-80P tester to an appropriate source of supply. Fuse holder provides access for Fuse replacement, and the Power Switch is used to turn the tester ON and OFF.
2	RS-232 Interface (Optional)	Apply a 5V (25mA) voltage signal for 500mS +/-200ms to start the Trigger process.
3	Interlock Switch (Optional)	Emergency Stop Close: Enables the tester buttons for operation. Open: Stops any process in the tester and disables the buttons. The TRIGGER and CHARGE Indicators will be blinking
4	Fuse replacement warning / Rating of power supply	Specifies replacement fuse and required supply voltage.

Waveform Measurement Setup

Testing

This section describes how the MegaPulse DF-80P tester is used to conduct a test. The test can be stopped immediately at any time by turning OFF the rear-panel power switch.

Connect the tester to a proper source of supply using the included 18 AWG power supply cord.Make sure that the front panel VOLTAGE adjust knob is turned fully counterclockwise.
Plug the Output and Return test leads into the jacks on the front panel.
Connect the ends of the test leads to the equipment under test.
Turn the Tester on. Toggle the POLARITY switch as needed so that the NOR or REV indicator is lit.
Note that the Voltage meter may indicate that some residual voltage is present on the main storage capacitor, even when the tester is first turned ON. This is due to inherent charging of the internal capacitors. Pressing the TRIGGER switch will discharge the capacitors (be sure not to touch the output and return leads when pressing the trigger switch).
Push the yellow CHARGE button. Verify the red TRIGGER indicator is now lit.
Adjust the VOLTAGE knob so that the front panel LED display is reading a voltage that is suitable for the measuring instrument that is being used. Push the red TRIGGER button, when the desired voltage is displayed on the front panel meter.
Note that the peak amplitude of the measured output waveform is proportional to the voltage that is read of the front panel of the MegaPulse, but it will always be somewhat lower. This is because the meter on the MegaPulse is measuring the voltage on the main impulse storage capacitor. This voltage will intentionally dissipate to some extent before reaching the output leads.

General Specifications
Max. Voltage:	5000 V
C1:	35uF
R1:	50 Ω
R2:	3.5 Ω
L1:	25mH Tests
Output Impedance:	50 Ω
Power Output:	360 Joules
Duty Cycle:	One pulse per minute. Faster duty cycles optional. Joules display
TestMinder PF USB Control:	Optional
Interlock:	Supplied
Relay Interface (PLC Interface):	Optional

0

Out of 5

Average Customer Review

Share your thoughts with other customers

Write a Review

Compare

Real people, here to help you.

Get Connected

Join the community and find out what we're up to, experience live product releases, webinars and more!

How Can We Help You?

Questions?

Log in to Your Account

Not a member yet? It's FREE!

Top Categories

Compliance West DF80 DSW AAMI DF-80 App DD Damped Sinusoidal Waveform

Recommended for you

MegaPulse Surge Tester

DSW AAMI DF-80 App DD Damped Sinusoidal Waveform

360J Output; 50 ohms Impedance Standard

Compliance West DF80 DSW AAMI DF-80 App DD Damped Sinusoidal Waveform

MegaPulse DF-80P Front Panel

MegaPulse DF-80P Rear Panel
