• Printing speeds up to 125mm/sec
• Long stencil life, Wide process window
• Halogen Free (EN14582 test method)
• Clear residue
• Low voiding

Printer Operation

• Print Speed: 25-125mm/sec
• Squeegee Pressure: 70-250g/cm of blade
• Under Stencil Wipe: Once every 10-25 prints, or as necessary

Stencil Life

• >8 hours @ 20-50% RH 22-28C (72-82F)
• >4 hours @ 50-70% RH 22-28C (72-82F)

Stencil Cleaning

• Automated stencil cleaning systems for both stencil and misprinted boards. Manual cleaning using isopropyl alcohol (IPA).

Storage and Handling

• Refrigerate at 3-8C (37-46F). Do not freeze. Allow 4 hours for solder paste to reach an operating temperature of 20-25C (68-77F) before use.

Transportation

• This product has no shipping restrictions. Shipping below 0C (32F) or above 25C (77F) for normal transit times by ground or air will not impact this product's stated shelf life.
