BLM-700A |
BLM-700B |
|
Digital Parts |
|
Resolution |
500 Mega Pixel |
500 Mega Pixel |
|
Photo Resolution |
2560X1920-1600X1200 |
2560X1920-1600X1200 |
|
Video Resolution |
640X480 |
640X480 |
|
Sensor Size |
1/2.5 Inches |
1/2.5 Inches |
|
LCD Screen |
8 Inches TFT Screen, Resolution is 800X 600 |
8 Inches TFT Screen, Resolution is 800X 600 |
|
Video Output |
AV Output (NTSC/PAL) |
AV Output (NTSC/PAL) |
|
Data Output |
USB2.0 |
USB2.0 |
|
Menu Language |
Chinese / English |
Chinese / English |
|
Storage |
SD Card Slot with Optional Memory Cards (Maximal Storage Capacity is 4G) |
SD Card Slot with Optional Memory Cards (Maximal Storage Capacity is 4G) |
|
Scene Mode |
Standard / Softness / Vivid |
Standard / Softness / Vivid |
|
Exposure Mode |
Auto Exposure |
Auto Exposure |
|
Date Mode |
Year, Month, Day, Hour, Minute |
Year, Month, Day, Hour, Minute |
|
Optical Parts |
|
Viewing Head |
Compensation Free Binocular ,Head Inclined at 30°,Interpupillary Distance 48-75mm |
Compensation Free Binocular ,Head Inclined at 30°,Interpupillary Distance 48-75mm |
|
Eyepiece |
Extra Wide Field Eyepiece EW10x/22 |
High-point ,Extra Wide Field Eyepiece EW10×/22 |
|
Objective |
|
LWD Infinite Plan Objective
4×/ 0.1, WD 18 mm
40×/ 0.6, WD 2.6mm |
Infinite Plan Achromatic Objective
4X/10X/40X/100X |
Infinite Plan Achromatic Objective
PH 10×/ 0.25, WD 10 mm
PH 20×/ 0.4, WD 5.1mm |
|
Nosepiece |
Backward Quintuple Nosepiece |
Quintuple |
|
Condenser |
Swing Condenser NA 0.9/ 0.25 |
ELWD Condenser NA 0.3, LWD 72 mm |
|
Focusing System |
Coaxial Coarse & Fine Adjustment, Fine Division 0.001mm |
Coaxial Coarse and Fine Adjustment, Vertical Objective Movement, Coarse Stroke 37.7 mm Per Rotation, Fine Stroke 0.2mm Per Rotation |
|
Stage |
Double Layers Mechanical Stage 185x142/ 75x55 mm |
Plain Stage 160×250 mm
Glass Insert
Auxiliary Stages70×180mm |
|
Kohler Illumination |
External Illumination, Aspherical Collector, Halogen Lamp6V/ 30W |
Halogen Lamp6V/ 30W |
|
Filter |
|
Blue ,Green and Ground Glass (45mm) |
|
Reflected Light Source |
Excitation |
Dichroic Mirror |
Barrier Filter |
Excitation |
Dichroic Mirror |
Barrier Filter |
|
Blue excitation |
Blue excitation |
|
BP460~490 |
BP460~490 |
BA520 |
BP460~490 |
DM500 |
BA520 |
|
Green excitation |
Green excitation |
|
BP510~550 |
DM570 |
BA590 |
BP480~550 |
DM570 |
BA590 |
|
Lamp |
100W HBO Ultra Hi-voltage Spherical Mercury Lamp |
100W HBO Ultra Hi-voltage Spherical Mercury Lamp |
|
Protection Barrier |
Barrier to Resist the Ultraviolet Light |
Barrier to Resist the Ultraviolet Light |
|
Power Supplier |
Power Supplier NFP-1,220V/ 110V Interchangeable ,Digital Display |
Power Supplier NFP-1,220V/ 110V Interchangeable ,Digital Display |
|
Immersion Oil |
Fluorescent Free Oil |
Fluorescent Free Oil |
|
Optional Parts |
|
Objective |
|
LWD Infinite Plan Objective
10×/ 0.25, WD 10mm
20×/ 0.4, WD 5.1mm |
Infinite Plan Achromatic Objective
20x |
Infinite Plan Phase Objective
PH 40×/ 0.6, WD 0.35mm |
Infinite Plan Fluorescent Objective
4x/10x/20x/40x,/100x |
Infinite Plan Fluorescent Objective
4×/ 0.13, WD 16.3mm
10×/ 0.3, WD 12.4mm
20×/ 0.4, WD 1.5mm
40×/ 0.6, WD 2.2mm |
|
Stage |
|
Attachable Mechanical Stage, X- Y Coaxial Control, Moving Range 120×78 mm |
|
|
Terasaki Holder |
|
|
38mm Petri Dish Holder |
|
|
54mm Slide Glass Holder |
|
Reflected Light Source |
Excitation |
Dichroic Mirror |
Barrier Filter |
Excitation |
Dichroic Mirror |
Barrier Filter |
|
Blue one excitation |
Blue one excitation |
|
BP460~495 |
DM505 |
BA510-550 |
BP460~495 |
DM505 |
BA510-550 |
|
Ultraviolet excitation |
Ultraviolet excitation |
|
BP330~385 |
DM400 |
BA420 |
BP330~385 |
DM400 |
BA420 |
|
Violet excitation |
Violet excitation |
|
BP400~410 |
DM455 |
BA455 |
BP400~410 |
DM455 |
BA455 |
|
Neutral ND25/ ND6 Filter |
Neutral ND25/ ND6 Filter |
|
|
Centering Telescope |
