Bacharach?s new Carbon Dioxide (CO2) Portable Gas Analyzer series is available in two models. Based on one common platform, the two models have new and improved operating software, the latest battery technology, USB data communications and flexible sensor options. In addition to CO2 infrared-based detection and measurement, each model offers optional sensors including oxygen, temperature and relative humidity. Infrared sensor technology is ideal for carbon dioxide detection as it offers accurate, reliable measurement with low maintenance costs.
Model 3100, equipped with a high-range CO2 infrared (IR) sensor measuring 0 ? 20%, is designed to be compatible with medical/ incubator applications, laboratory use, soil gas analysis, agriculture and horticulture applications. The CO2 Portable Gas Analyzers have a powerful internal pump, new and improved operating software, the latest battery technology, USB data communications and flexible sensor options. In addition to carbon dioxide detection and measurement, Model 3100 offers optional sensors including oxygen, temperature and relative humidity.
Infrared sensor technology is ideal for carbon dioxide detection as it offers accurate, reliable measurement with low maintenance costs. The Bacharach CO2 Analyzer Model 3100 is ideal for incubator CO2 verification. The analyzers accurately and quickly confirm the CO2, O2, relative humidity (RH) and temperature levels.
| MEASURING RANGES |
| Measurement | Reading | Resolution |
| CO2 (high) | 0-20% | 0.1% |
| O2 | 0-100% | 0.1% |
| Temperature* | 32?F - 122?F (0 - 50?C | 0.1?F |
| Relative Humidity* | 0-100% | 1% |
| *Optional. RH option must be chosen at the time of the order. |
