Bacharach 0077-7072 Discontinued Products

Name: Bacharach 0077-7072 Discontinued Products
Brand: Bacharach
SKU: Bacharach0077-7072
Availability: InStock

0 reviews | Model: Bacharach 0077-7072

Compare

Bacharach 0077-7072

5 HP Electric Drive Motor
Digital fuel delivery measurement
Floor Standing Unit; full welded frame construction
Operating speed 2000 rpm
Cast Iron Cambox with tapered roller bearings and quick change cam capability
Injector Clamping: hydraulic, with mechanical lock
Calibration fluid reservoir capacity: 8 U.S. Gallons (30 liters)

View Product Details

In Stock:

View Payment Options

Non-Cancellable / Non-Returnable

Recommended for you

Filtration:	Primary filter (spin-on type): 10 micron Final stage filter (spin-on type): 3 micron Flowmeter transducer: Screen
Calibration fluid temperature control:	Solid state control 100 ±1 °F (factory setting) Cooling by cold tap water Heating by two 500 watt immersed electric heaters
Instrumentation & Controls:	Injector Supply (Rail) Pressure Gauge, 4" dial, 0-100 psi Calibration Fluid Temperature Gauge, dual scale: 40-140 °F (5-60 °C) Supply Pressure Regulator Clamping Pressure Regulator Main Drive Start/Stop Switch Measurement System Start Switch
Measurement System:	Positive Displacement Flowmeter (U.S. patent No. 4141243) Measurement Units: mm3/str. Digital display resolution: 0.1 mm3/str. Measurement period: 100 strokes Stroke counter: electronic/optical Accuracy: ±0.75% of reading, or 1 mm3/str., whichever is greater
Indicator Lights:	Power (red) Heat/Cool (amber) Clamping (amber)
Accessibility:	Two front and one upper-left hand side hinged doors. All other panels have quick turn fasteners for easy removal.
Dimensions:	50" W x 30" D x 56" H (1.27 x 0.76 x 1.42 m)
Weight (dry):	1150 lbs (522 kg)
Utilities Required:	Power Supply: 230 VAC, 3 Phase, 60 Hz, 30 Amps (standard). Other voltages/frequencies available. Air Pressure: 80-120 psi (2 CFM) Water: Cold tap, approx. 1.2 GPM (4.5 liter/min)
Accessories:	All the required accessories are included for mounting and testing Detroit Diesel 53, 71, 92, 149 and 8.2L Mechanical Unit Injectors. Provision for hanging all accessories on pegboard inside front door
