Refrigerants |
Category III |
R12, R134a, R401c, R406a, R500 |
Category IV |
R22, R401a, R401b, R402b, R407c, R407d, R408a, R409a, R411a,
R411b, R412a, R502, R509 |
Category V |
R402a, R404a, R407a, R407b, R410a, R507 |
Compressor Type |
2-Cylinder, Oilless, Air-cooled |
Motor |
1HP, 1,450 RPM @ 50Hz; 1,750 RPM @ 60Hz |
Vacuum Rating |
15” Hg+ |
High Pressure Shut-Off |
558 PSI (38.5 bar; 3,850 kPA) |
Low Pressure Shut-Off |
≥14 ±2 Hg |
Auto 80% Tank Shut-Off |
Yes, optional feature |
R410a Recovery Rates |
Vapor Recovery Rate: 0.55 lbs./min. (0.25 kg/min.)
Liquid Recovery Rate: 5.71 lbs./min. (2.59 kg/min.)
Liquid Push / Pull: 15.85 lbs./min. (7.19 kg/min.) |
R134a Recovery Rates |
Vapor Recovery Rate: 0.46 lbs./min. (0.21 kg/min.)
Liquid Recovery Rate: 4.52 lbs./min. (2.05 kg/min.)
Liquid Push / Pull: 10.89 lbs./min. (4.94 kg/min.) |
R22 Recovery Rates |
Vapor Recovery Rate: 0.55 lbs./min. (0.25 kg/min.)
Liquid Recovery Rate: 6.35 lbs./min. (2.88 kg/min.)
Liquid Push / Pull: 11.40 lbs./min. (5.17 kg/min.) |
Operating Temperature |
32˚ to 104˚ F (0˚ to 40˚ C) |
Power Supply |
110-120 VAC, 60Hz 10 A; 220-240 VAC, 50/60Hz, 5 A;
100 VAC, 50/60Hz, 10 A |
Dimensions |
16.125“ x 10.25” x 13.75” (410 x 260 x 350mm) |
Weight |
28.5 lbs. (12.9 kg) |
Approvals |
CE, Recovery rates per AHRI 740 |
Warranty |
12-month on unit |
