• Voltage: 0-60 V (Ch1 & Ch2), 0-5 V (Ch3)
• Current: 0-3 A (Ch1, Ch2), 0-3 A (Ch3)
• Power: 375 W
• Three independent and electrically isolated outputs
• Displays voltage and current settings for all three channels simultaneously

The BK Precision 9132B is a triple output DC power supply offering output rating of 0-60 V (Ch1 & Ch2), 0-5 V (Ch3) of voltage, 0-3 A (Ch1, Ch2), 0-3 A (Ch3) of current, and 375 W of power.

This triple output linear programmable DC power supply features isolated outputs that can be adjusted independently or combined in series or parallel to output higher voltage or current. Additionally, this power supply can operate in tracking mode with user-configurable ratios between channels.

The front panel keys and rotary knob with convenient cursors let users quickly set voltage and current values. Up to 36 different instrument settings can be saved and recalled. The power-on state of the outputs can also be configured.

For remote control, the standard USB (USBTMCcompliant), RS232 interfaces supporting SCPI commands can be used to remotely control the power supplies via a PC. Alternatively, users can control the power supply, execute test sequences, or log measurements using the provided PC software application. This software also integrates with Data Dashboard for LabVIEW apps enabling iOS, Android, or Windows 8 compatible tablets or smartphones to remotely monitor select measurement indicators.

This power supply is suitable for a wide range of applications including production testing, telecommunications, R&D, electronic service, and labs.
