Sine: 1 µHz to 50 MHz Square: 1 µHz to 50 MHz Triangle, Ramp: 1 µHz to 5 MHz Pulse: 0.5 mHz to 25 MHz Accuracy: 0.001 % (10 ppm) Resolution: 12 digits or 1 µHz Built-in Waveforms: Sine, Triangle, Square, Noise, Ramp Up, Ramp Down, Sine(X)/X, Exponential Up, Exponential Down, Gaussian Waveform Length: 2 points to 4,000,000 points Vertical Resolution: 14 bits (16,384 levels) Noise: Add 1% to 100% to output waveform Sampling Rate: 125 MSa/s, Point execution rate adjustable from 8 ns-100 s Frequency: Accuracy: 0.001% (10 ppm)Resolution: 4 digits or 1 ps Amplitude Range: 10 mV to 10 Vp-p into 50 O Amplitude Resolution: 3 digits (1000 counts) Amplitude Accuracy (1 kHz): ? 1% ? 20 mV of programmed output from 1 V ? 10 V Flatness (relative to 1 kHz): ? 0.1 dB to 10 MHz ? 1 dB to 50 MHz Offset Range: ? 4.99 V into 50 O, depending on the Amplitude setting Offset Resolution: 10 mV with 3 digits resolution Offset Accuracy: ? 1% ? 10 mV into 50 O Output Impedance: 50 O typical Output Protection: The instrument?s output is protected against short circuit or nominal accidental voltages applied to the main output connector Filter: 9 pole Elliptic and 5 pole Bessel filters Harmonic Distortion (sine): DC-20 kHz, -65 dBc20 kHz-100 kHz, 60 dBc100 kHz-5 MHz, -45 dBc5 MHz-50 MHz, -35 dBc Spurious (sine): DC-1 MHz -65 dBc Rise/Fall Time (square, pulse): 6 ns (10% to 90%) at full amplitude into 50 O Variable Duty Cycle: 20% to 80% to 10 MHz (square)40% to 60% to 30 MHz (square)50% 30 MHz (square) Variable Symmetry: 10%-90% to 5 MHz (triangle) Symmetry at 50%: 0.5 % Linearity (triangle, ramp): 0.1% of peak output (1 µHz to 250 kHz) Aberrations: 3 % of p-p amplitude ? 50 mV Pulse Width: 20 ns to (Period-20 ns)(10 ns resolution) Variable Edge Time: 100 ns to Width/0.625 (50 % duty cycle) 10 ns resolution Continuous: Output continuous at programmed parameters Triggered: Output quiescent until triggered by an internal or external trigger, then one waveform cycle is generated to programmed parameters. Up to 20 MHz trigger Gate: Same as triggered mode, except waveform is executed for the duration of the gate signal. The last cycle started is completed Burst: 2-999,999 cycles Phase: -180 to +180 degrees with 0.1 degree resolution Trigger Source: Trigger source may be internal, external or manual. Internal trigger rate 0.01 Hz-1 MHz (1 µs ? 100 s) Internal: 0.01 Hz-20 kHz sine , square or triangle waveform variable modulation from 0% to 100% External: 5 Vp-p for 100% modulation, 10 kO input impedance, 0.01 Hz ? 50 KHz bandwidth Internal: 0.01 Hz-20 kHz sine wave, square or triangle External: 5 Vp-p for 100% deviation, 10 kO input impedance0.01 Hz ? 50 kHz bandwidth Internal: 0.01 Hz to 1 MHz External: 1 MHz max. Sweep Shape: Linear and Logarithmic, up or down Sweep Time: 10 ms to 500 s Sweep Trigger: internal, external, continuous or burst Trigger IN: TTL CompatibleMaximum rate 20 MHzMinimum width 20 nsInput Impedance10 kO nominal Sync OUT: TTL pulse at programmed frequency, 50 O source impedance Modulation IN: 5 Vp-p for 100% modulation10 kO input impedanceDC to 50 kHz minimum bandwidth Marker Out: Positive TTL pulse user programmable in Arbitrary waveform, 50 O source impedance Reference IN-OUT: 10 MHz, TTL compatible, input or output, for external unit synchronization 50 O output impedance and 1 kO input Summing IN: 5 Vp-p signal for full scale output, 500 O input impedance Repetition: 1 ms to 100 s Resolution: 4 digits Accuracy: ?0.002% Display Resolution: 160 x 80 dots LCD Remote Control Interface: GPIB, RS-232 Store Memory: 50 full panel settings at power-off Dimensions (WxHxD): 8.4(213) x 3.5(88) x 10.8(275) inches (mm) Weight: Approx. 2.5 kg (5.55 lbs) Power: 100-240 VAC 10%, 50 VA max. Temperature: Operating 0 ?C to + 50 ?CNon-operating -20 ?C to + 70 ?C Humidity: 95 % RH , 0 ?C to 30 ?C EMC: According to EN55011 for radiated and conducted emissions Electrical Discharge Immunity: According to EN55082 Safety Specifications: According to EN61010 , CE approved |
