| Constant Voltage Operation |
Voltage Regulation
Line (120VAC +- 10%) |
<=0.2% + 2mV |
| Load (no load - full load) |
<=0.04% + 2 mV |
| Constant Current Operation |
Current Regulation
Line (120VAC +- 10%) |
<=0.4% + 5mA |
| Overload Protection |
Current limiting, reverse polarity, overvoltage, short circuit |
| Power Requirements |
120 VAC +- 10%, 60 Hz only (120/220/230/240 VAC +- 10%, 50/60 Hz version available) |
| Operating Temperature |
320 to 104 0 F (0 0 to 40 0 C). <=75% R.H |
| Storage Temperature |
5 0 to 158 0 F (-15 0 to 70 0 C). <=85% R.H |
| Dimensions (HxWxD) |
5.7x10.5x15'' (145x267x381 mm) |
| Optional |
Hook-up leads - up to 5 amps Model TL-5A, up to 30 amps Model TL-30 |
