| Models |
30-2032 Battery Powered
30-2036 Battery Powered. In-Line
30-2132 4-20 mA Loop Powered
30-2136 4-20 mA Loop Powered. In-Line
30-2232 12-36 VDC Line Powered
30-2236 12-36 VDC Line Powered. In-Line |
| Accuracy |
0.25% Full Scale, Terminal Point Accuracy |
| Case Size |
3 inch |
| Case Material |
Stainless Steel |
| Wetted Parts |
316L Stainless Steel |
| Enclosure |
Weatherproof Nema4, IP65 |
| Connection and Finish |
1-1/2" and 2" Tri-Clamp. Direct, In-Line, Remote
12-20 Ra Finish |
| Fill Fluid |
Glycerine (standard)
Silicone (optional)
Food Grade Mineral Oil (optional)
NOTE: Vacuum and compound pressure ranges require food grade mineral oil fluid option (MY) |
| Connection Location |
Lower |
| Process Temperature |
14°F / 275°F (–10°C / 135°C) to withstand clean in place
(CIP) & steam in place (SIP). Re-zero gauge often after exposure to elevated temperatures and use |
| Ambient Temperature |
14/140°F (-10/60°C). WARNING: Do not use in an Autoclave |
| Temp. Error (Zero & Span) |
±.22% per 10°F, (12°F) (Span and Zero shift can be eliminated by rezeroing the gauge at operating temperatures. Temperatures must be within process temperature limits) |
| Storage Temperature |
–4/158° (–20°/70°F) |
| Overrange Pressure |
2x range of gauge |
| Type |
LCD |
| # Digits |
5 |
| Character Height |
0.60" |
| Backlite |
Optional. Requires Battery Backup option if Loop Powered versions (30-2132, 30-2136) ordered |
| Bar Graph |
Yes |
| Battery |
3" (2) AA Alkaline |
| Battery Life |
3" 1000+ |
| Agency Approvals |
CE (excludes XRE option) |
| On/Off |
Manually turns unit on and off (auto off options
in menu) |
| Zero/Clear |
Zeros display or clears min. and max. values
when displayed |
| Min/Max |
Down Arrow Key: Stores min and max values, arrow key allows for scrolling thru menu items |
| Menu Key |
Provides access to menu options |
| Backlite (optional) |
Up Arrow Key (Backlite optional):
Manually turns backlite on and off (auto off options in menu), arrow key allows for five menu options. Up arrow key allows for scrolling thru menu options |
| Enter |
Selects items in the menu |
| Engineering Units |
12 units of measurement are available:
psi, In. H2O (with three temp. options: 20°C, 60°F, 4°C), Ft. H2O, mPa, mBar, kPa, kg/cm2, Bar, inHg and mmHg |
| Configuration Mode (Config) |
Allows for changes to default settings of gauge including zero disable feature |
| Bar Graph (Graph) |
Allows for adjustment of bargraph and optional 4-20 |
| Auto Off (Off) |
Allows for changes to auto off of gauge, five options: Never, 2 min., 5 min., 15 min., 30 min |
| Update Rate (Update) |
Four options: 100 ms, 200 ms, 500 ms, 1 sec |
| Dampening (Damp) |
Six options: None, average, 2, 4, 6, 8 times per 100ms |
| Backlite |
Five options: Never, 10 sec., 30 sec., 1 min., 5 min |
| Zero Disable |
Zero "lockout" feature |
| Field Recalibration |
Allows for recalibration of zero, midscale and span (password protected) |
