| ARMASIGHT TAT166MN1HDPR41 General Specifications |
| Refresh Rate |
60 Hz |
| Magnification (NTSC/PAL) |
3.7× / 4.4× |
| Objective Lens Type |
Germanium |
| Type of Focal Plane Array |
FLIR Tau 2 |
| Pixel Array Format |
640×512 |
| Pixel Size |
17 µm |
| Display Type |
AMOLED SVGA 060 |
| Pixel Display Format |
800×600 |
| Display Brightness |
Discretely Adjustable to 8 Levels |
| Turn-on Time, max |
3 sec |
| Digital Zoom |
1x, 2x, 4x, and 8x |
| Image Palettes |
White Hot, Black Hot, Fusion, Rainbow, Globow, Ironbow 1, Ironbow 2, Sepia, Color 1, Color 2, Ice-Fire, Rain, and OEM Custom |
| Analog Input and Output Format (resolution) |
PAL (768×574 pixels)/ NTSC (640×480 pixels) |
| Video Recording |
Optional Digital Video Recorder with SD card slot |
| Remote Control |
Wireless |
| Active Contrast Enhancement (ACE) - “CONTRAST” |
Yes |
| Second Generation Digital Detail Enhancement (DDE) – “SHARPNESS” |
Yes |
| Smart Scene Optimization (SSO) – “SMART SCENE” |
Yes |
| Automatic Gain Control (AGC) |
Yes |
| User-Controlled Manual Non-Uniformity Correction/Flat-Field Correction (UCMNUC/FFC) |
Yes |
| Silent Shutterless NUC ™ (SSN) |
Yes |
| Objective Focal Length |
100 mm |
| Objective F-number |
1:1.3 |
| Field of View (ang.) |
6.2° x 5.0° |
| Exit Pupil Diameter |
14 mm |
| Eye Relief |
25 mm |
| Focus Method |
Manual |
| Focusing Range |
10m to inf. |
| Diopter Adjustment |
Manual |
| Diopter Adjustment Range |
±5 diopter |
| Battery |
Two CR123A 3V Lithium batteries or CR123 type rechargeable batteries with voltage from 3.0V to 3.7V (2)*
* Rechargeable batteries with voltage 3.0V-3.7V can be used only in devices with serial number starting from 140885 |
| Battery Life at 20 °C (68 °F) |
Up to 4 hr (optional up to 12 hrs) |
| Extended Battery Pack |
Two 18650 rechargeable batteries (3.7V), four CR123 rechargeable batteries with voltage 3.7V max, or four standard CR123A 3V Lithium batteries (operational time up to 8 hr) |
| External Power Supply |
6 VDC/ 600m" |
| Operating Temperature |
-40° to +50°C (-40° to +122°F) |
| Storage Temperature |
-50° to +70°C (-58° to +158°F) |
| Impact Loading |
700 g |
| Environmental Rating |
Water and Fog-Resistant |
| Overall Dimensions |
239 x 116 x 11mm (9.4 x 4.6 x 4.6 in) |
| Weight (w/o Batteries) |
1.1 kg (2.4 lbs) |
| Warranty |
3 Years |
| Warranty on FLIR Detector |
10 Years |
