| General Specifications |
| Refresh Rate |
60 Hz |
| Magnification (NTSC/PAL) |
6.7x / 8x |
| Objective Lens Type |
Germanium |
| Type of Focal Plane Array |
FLIR Tau 2 |
| Pixel Array Format |
336x256 |
| Pixel Size |
17 µm |
| Resolution |
0.17 mRad (35 SOA) |
| Display Type |
AMOLED SVGA 060 |
| Pixel Display Format |
800x600 |
| Display Brightness |
Discretely Adjustable to 8 Levels |
| Turn-on Time, max |
3 sec |
| Digital Zoom |
1x, 2x, and 4x |
| Digital Compass |
Yes |
| Digital Inclinometer |
Yes |
| Digital Angle Cosine Indicator |
Yes |
| Battery Status Indicator |
Yes |
| Image Palettes |
White Hot, Black Hot, Sepia, Fusion, Rainbow, and Rain |
| Analog Input and Output Format (resolution) |
PAL (768×574 pixels)/ NTSC (640×480 pixels) |
| Video Recording |
Optional Digital Video Recorder with SD card slot |
| Remote Control |
Wireless 5-button |
| Active Contrast Enhancement (ACE) - “CONTRAST” |
Yes |
| Second Generation Digital Detail Enhancement (DDE) – “SHARPNESS” |
Yes |
| Smart Scene Optimization (SSO) – “SMART SCENE” |
Yes |
| Linear Automatic Gain Control - “AGC" |
Yes |
| Information-Based Histogram Equalization (IBHEQ) – “SKY/SEA” |
Yes |
| User-Controlled Manual Non-Uniformity Correction/ Flat-Field Correction (UCMNUC/ FFC) |
Yes |
| Silent Shutterless NUC ™ (SSN) |
Yes |
| Objective Focal Length |
100 mm |
| Objective F-number |
1:1.4 |
| Field of View (ang.) |
3.3° ? 2.5° |
| Exit Pupil Diameter |
14 mm |
| Eye Relief |
16 mm |
| Focus Method |
Manual |
| Focusing Range |
10m to inf. |
| Diopter Adjustment |
Manual |
| Diopter Adjustment Range |
±5 diopter |
| Battery |
Four CR123A 3V Lithium batteries or four AA 1.5V |
| Battery Life at 20 °C (68 °F) |
Up to 7 hr (optional up to 14 hrs) |
| Extended Battery Pack (optional) |
Two 18650 rechargeable batteries (3.7V) or four CR123 type rechargeable batteries with voltage 3.7V max or four standard CR123A 3V Lithium batteries (operational time up to 7 hr) |
| External Power Supply |
6 VDC/ 600m? |
| Operating Temperature |
-51° to +57°C (-59° to +134°F) |
| Storage Temperature |
-57° to +85°C (-70° to +185°F) |
| Impact loading |
700g |
| Environmental Rating |
Water and Fog-Resistant / Waterproof (optional) |
| MIL-STD-810 Compatibility |
Yes |
| Overall Dimensions |
309 x 102 x 90 mm (12.1 x 4.0 x 3.5 in) |
| Weight (w/o Batteries) |
1.4 kg (3.1 lbs) |
| Warranty |
3 Years |
| Warranty on FLIR Detector |
10 Years |
