| Display |
5 Digit LCD with bar graph indicator |
| Unit of Measurement |
m/s (meters per second)
km/h (kilometer per hour)
ft/min (feet/per minute)
knots (nautical miles per hour)
mph (mile/h, miles per hour)
Temp. (°C, °F)
Data hold |
| Sensor Structure |
Air velocity sensor: Conventional twisted vane armand low friction ball bearing design
Temperature sensor: Precision thermistor |
| Sampling Time of Data Logger |
Manual:Pushing the data logger button once will |
save data one time
Auto |
1, 2, 10, 30, 60, 600, 1800, 3600 seconds |
| Air Velocity |
| m/s |
Range- 0.4 - 25.0m/s
Resolution - 0.1m/s (>10m/s)
0.01m/s (<10m/s)
Accuracy*- +(2% + 0.2m/s) |
| km/h |
Range-1.4 - 90.0km/h
Resolution-0.1km/h
Accuracy*- +(2% + 0.2m/s) |
| mph |
Range 0.9 - 55.9mph
Resolution 0.1mph
Accuracy* +(2% + 0.2m/s) |
| knots |
Range 0.8 - 48.8knots
Resolution 0.1knots
Accuracy* +(2% + 0.2m/s) |
| ft/min |
Range 80 - 4930ft/min
Resolution 1ft/min
Accuracy* +(2% + 0.2m/s) |
| Temperature |
| Measuring Range |
0° to 50°C / 32° to 122°F |
| Resolution |
0.1°C / 0.1°F |
| Accuracy* |
+0.8°C / 1.5°F |
| Over Range Indicator |
" _ _ _ _ " |
| Data Hold |
Display freeze |
| Memory |
Saves MAX. or MIN values with recall |
| Sampling Time |
Approximately 0.8 seconds |
| Power Off |
Auto or manual control |
| Data Output |
RS-232 Serial data output |
| Operating Environment |
32° to 122°F (0° to 50°C), <80% R.H. |
| Power Supply |
Pieces of DC 1.5V Batteries (UM4, AAA or equivalent) |
| Weight (approx.) |
0.85lbs. (387g) |
| Dimensions (approx.) |
Main instrument: 6.9 x 2.7 x 1.7" (174 x 68 x 42mm)
Sensor probe diameter: 2.8" (72mm) |
| Included Accessories |
Instruction manual, battery, carrying case |
