| Display Type |
Liquid-crystal (LCD), 4-1/2 digits, maximum reading 19999 |
| Measurement Method |
Digital, triaxial measurement |
| Directional Type |
Isotropic (triaxial) |
| Range Selection |
One continuous range |
| Resolution |
0.1mV/m, 0.01V/m, 0.1µA/m, 0.1mA/m, 0.001µW/m2, 0.01mW/ m2, 0.001µW/cm2 |
| Setting Time |
Typically 1.5s (0 to 90% measurement value) |
| Sample Rate |
1.5 times per second |
| Units |
mV/m, V/m, µA/m, mA/m, µW/m2, mW/m2, µW/cm2 |
| Display Value |
Instantaneous measured value, maximum value, average value, or maximum average value |
| Audible Alarm |
Buzzer |
| Alarm Function |
Adjustable threshold with ON / OFF |
| Calibration Factor |
Adjustable |
| Data Storage/Recall |
200 Data Sets |
| Batteries |
9V |
| Battery Life |
Approximately 3 hours |
| Auto Power-Off |
Default time 15 minutes. Adjustable threshold 0~99 minutes |
| Dimensions |
370(L) x 80(W) x 80(H) mm |
| Weight |
Approx. 400g (including battery) |
| Electrical Specifications |
| Sensor Type |
Electrical Field (E) |
| Frequency Range |
10MHz ~ 8 GHz |
| Specified Measurement Range |
CW signal (f >50MHz):
o 38 mV/m to 11.00 V/m
o 53.0 µA/m to 28.64 mA/m
o 0.1 µA/m2 to 309.3 mW/m2
o 0µ W/cm2 to 30.93 mW/cm2 |
| Dynamic range |
Typically 75dB |
| Absolute error at 1V/m and 2.45GHz |
± 1.0 dB |
| Frequency Response |
Sensor taking into account the typical CAL factor:
o ±2.4dB(50 MHz to 1.9 GHz, 3.5 GHz to 8GHz)
o ±1.0dB (1.9 GHz to 3.5GHz) |
| Isotropy deviation |
Typically ±1.0dB (2.45GHz) |
| Overload limit |
0.083mW/cm2, (17.7 V/m) per axis
(0 to 50°C): ±0.2dB |
