| Display Type |
Liquid-crystal (LCD), 4-1/2 digits, maximum reading 19999 |
| Measurement Method |
Digital, triaxial measurement |
| Directional Type |
Isotropic (triaxial) |
| Range Selection |
One continuous range |
| Resolution |
0.1mV/m, 0.1µA/m, 0.001µW/m2, 0.001µW/cm2 |
| Setting Time |
Typically 1.5s (0 to 90% measurement value) |
| Sample Rate |
3 times per second |
| Units |
mV/m, V/m, µA/m, mA/m, µW/m2, mW/m2, µW/cm2 |
| Display Value |
Instantaneous measured value, maximum value, average value, or maximum average value |
| Audible Alarm |
Buzzer |
| Alarm Function |
Adjustable threshold with ON / OFF |
| Calibration Factor |
Adjustable |
| Data Storage/Recall |
200 Data Sets |
| Batteries |
9V |
| Battery Life |
Approximately 15 hours |
| Auto Power-Off |
Default time 15 minutes. Adjustable threshold 0~99 minutes |
| Dimensions |
60(L) x 60(W) x 195(H) mm |
| Weight |
Approx. 200g (including battery) |
| Electrical Specifications |
| Sensor Type |
Electrical field (E) |
| Frequency Range |
50MHz ~ 3.5GHz |
| Specified Measurement Range |
CW signal (f >50MHz):
o 38mV/m to 20.00V/m
o 53.0µA/m to 53.74mA/m
o 0.1µW/m 2 to 1.089W/m2
o 0.001µW/cm 2 to 108.9µW/cm2 |
| Dynamic Range |
Typically 75dB |
| Absolute error at 1V/m and 2.45GHz |
2.45GHz: ±1.0 dB |
| Frequency Response |
Sensor taking into account the typical CAL factor:
o ±2.4dB (50 MHz to 1.9 GHz)
o ±1.0 dB (1.9 GHz to 3.5GHz) |
| Isotropy Deviation |
Typically ±1.0 dB (2.45GHz) |
| Overload Limit |
0.42mW/cm2, (11 V/m) per axis
(0 to 50°C): ±0.2dB |
