Amprobe MAN30 Differential Pressure Manometer

Name: Amprobe MAN30 Differential Pressure Manometer
Brand: Amprobe
SKU: AmprobeMAN30
Price: 204.88 USD
Availability: InStock

0 reviews | UPC: 095969499248 | Model: Amprobe MAN30

Compare

30 PSI MANOMETER

Measuring range up to 30 PSI (206.9 kPA)
Necessary tool for gauge and differential pressure measurement
Perfect for applications such as: valves, control sensors a pneumatic control environment, HVAC/R pressure levels and medical pressure systems
11 selectable units of measure: bar, mmHg, ozin2, kgcm2, psi, inH2O, kpa, ftH2O, inHg, cmH2O, mbar
Maximum and Minimum value recordings with time stamp help adjust and trouble shoot the pressure systems
Data Hold
Large backlight LCD
Auto power off function
Built-in computer USB port for data downloads with optional PC cable and software
Includes connection hoses
Hard Carrying Case
1 X 9V Alkaline Battery (NE DA 1604A, IE C 6LR61) included

View Product Details

List Price: $277.70

In Stock:

Recommended for you

Accuracy	Max 1% full scale at 25°C (77°F)
Response Time	0.5 second
Sensitivity
Resolution	0.01 psi / 0.1kpa / 0.5mmHg / 0.001 kg/cm2 1 hpa / mbar, 0.001 bar, 0.3inH2O, 1cmH2O, 0.02 ftH2O, 0.2 oz/inch2
Battery Life	14 hours
Electrical
Battery	1 X 9V Alkaline Battery (NE DA 1604A, IE C 6LR61) included
Mechanical
Dimension	182 x 72 x 30 mm (7.16 x 2.83 x 1.18 in)
Weight	0.220 Kg (0.485 lb)
Case	Hard Carrying Case
Environmental
Operating Humidity	80% RH
Operating Temperature	0°C to 50°C / 32°F to 122°F
Storage Temperature	-20°C to 60°C / -4°F to 140°F
Agency Approvals & Certifications	CE

HVAC Equipment and Instruments/Manometer Template
Type (Manometer)	Digital
Max Pressure	30 psi (830.40 IN of H2O)
Type of Input	Dual
Engineering Units (HVAC)	inch H2O, inch Hg, kPa, mmHg, psi
Measurement	Differential, Gauge
Min/Max/Hold	Yes
Anemometer Capability	No
Altitude Capability	No
Test Equipment General Attributes
Unique Features	Measuring range up to 30 PSI (206.9 kPA) Necessary tool for gauge and differential pressure measurement Perfect for applications such as: valves, control sensors in a pneumatic control environment, HVAC/R pressure levels and medical pressure systems 11 selectable units of measure. Maximum and minimum value recordings with time stamp help adjust and trouble shoot the pressure systems Auto power off function Built-in computer USB port for data downloads with optional PC cable and software
Warranty	1 YEARS
Product Weight	0.485 LBS Product Weight 0.220 Kg
Product Height	1.18 IN
Product Length	7.16 IN Product Length 182 x 72 x 30 mm
Product Width	2.83 IN
Data Logging	No
Country of Origin	China
Shipping Height	2.75 IN
Shipping Length	12.00 IN
Shipping Width	8.00 IN
